Configure trays
The MFP automatically prompts you to configure a tray for type and size in the following situations:
●
When you load paper into the tray
●
When you specify a particular tray or media type for a print job through the printer driver or a
software program and the tray is not configured to match the print-job’s settings
The following message appears on the control panel:Tray <X> [type] [size] To change size or type,
touch “Modify”. To accept, touch “OK”..
NOTE The prompt does not appear if you are printing from tray 1 and tray 1 is configured for
Any Size and Any Type.
NOTE If you have used other HP LaserJet printer models, you might be accustomed to
configuring tray 1 to First mode or Cassette mode. On HP Color LaserJet CM4730 MFP series,
setting tray 1 size and type to Any Size is equivalent to First mode. Setting size or type for tray 1
to a setting other than Any Size is equivalent to Cassette mode.
Configure a tray when loading paper
1. Load paper in the tray. Close the tray if you are using tray 2, 3, or 4.
2. The tray configuration message appears.
3. Touch OK to accept the detected size, or touch Modify to choose a different paper size.
4. If modifying the tray configuration, select the size.
NOTE The MFP automatically detects most media sizes in trays 2, 3, and 4.
5. If modifying the tray configuration, select the paper type.
6. Touch Exit.
Configure a tray to match print job settings
1. In the software program, specify the source tray, the paper size, and the paper type.
2. Send the job to the MFP.
If the tray needs to be configured, the LOAD TRAY X: message appears.
3. If the highlighted size is not correct, touch X MILLIMETERS. Then use the numeric keypad to set
the X and Y dimensions.
4. If the highlighted paper type is not correct, touch Paper Handling and select the paper type.
5. Touch OK.
6. Touch Exit.
