SIS Programmer’s Guide, cont’d
USP 507 • SIS Programmer’s Guide
4-12
Command ASCII command
(host to processor)
Response
(processor to host)
Additional description
Scan converter horizontal size
Specific value
ESX1&HSIZ}
HsizS
X1&]
Set horizontal size to
X1&
.
Increase size
ES+HSIZ}
HsizS
X1&]
Widen image.
Decrease size
ES-HSIZ}
HsizS
X1&]
Make image narrower.
View
ESHSIZ} X1&]
Horizontal size is
X1&
.
Scan converter vertical size
Specific value
ESX1&VSIZ}
VsizS
X1&]
Set vertical size to
X1&
.
Increase size
ES+VSIZ}
VsizS
X1&]
Make image taller.
Decrease size
ES-VSIZ}
VsizS
X1&]
Make image shorter.
View
ESVSIZ} X1&]
Vertical size is
X1&
.
Scan converter horizontal filter
Set detail level
ESX7&HDET}
HdetS
X7&]
Set H filter level to
X7&
.
Increment up
ES+HDET}
HdetS
X7&]
Increase H filter level.
Increment down
ES-HDET}
HdetS
X7&]
Decrease H filter level.
View detail value
ESHDET} X7&]
H filter level is
X7&
.
Scan converter flicker filter
Set flicker filter level
ESX7&VDET}
VdetS
X7&]
Specify the flicker filter level
to
X7&.
Increment up
ES+VDET}
VdetS
X7&]
Increase the flicker filter level
.
Increment down
ES-VDET}
VdetS
X7&]
Decrease the flicker filter level
.
View flicker filter level
ESVDET} X7&]
View the flicker filter level
.
Scan converter encoder filter
Set encoder filter level
ESX7&VENC}
VencS
X7&]
Set video encoder filter level
to
X7&
.
View
EVENC} X7&]
View the encoder filter level
.
Presets
User presets
Recall presets
1*
X2%.
1Rpr
X2%]
Recalls user preset
X2%
for
selected input.
Save presets
1*
X2%,
1Spr
X2%]
Saves user preset
X2%
for
selected input.
Input presets
Recall presets
2*
X2^.
2Rpr
X2^]
Recalls input preset
X2^
.
Save presets
2*
X2^,
2Spr
X2^]
Saves input parameters to
preset
X2^
.
PIP presets
Recall presets
3*
X2%.
3Rpr
X2%]
Recalls PIP preset
X2%
.
Save presets
3*
X2%,
3Spr
X2%]
Saves PIP layout to preset
X2%
.
N
X1&
= H and V size: 0 to 200% of the output area in single pixel increments
X2%
=
Memory/PIP presets 1 to 16
X2^
=
Input presets 1 to 128
X7& = Filter level 0 to 3
