Connect the D77B-DSNAP to DeviceNet
Connect the DeviceNet cable to the 5-position DeviceNet Connector located at the top of the
D77B-DSNAP.
The 5-position DeviceNet Connector has screws for positive retention that need to be
loosened to remove the terminal block.
The D77B-DSNAP will work with thick and thin media.
The DeviceNet cable is color-coded and matches the colors on the DeviceNet
connector.
Use only one wire per terminal.
Tighten the screws to 0.5 Nm (4.5 lb-in).
For further information on DeviceNet wiring practices and power considerations, refer to the
DeviceNet Installation Planning Guide
, Publication Number SA-370.
Table 8: DeviceNet Connection
Connector Legend DeviceNet Wire Signal
V+ Red +24V DC
CH White CAN High
D Shield Shield
CL Blue CAN Low
V- Black Signal Common
