APX200.2M Power System Amplifier
INTRODUCTION
The Clarion APX200.2M is a full-featured two-channel amplifier incorporating
the following features:
• Full frequency response with low distortion and exceptional signal to noise
performance
• Advanced circuit design that features bridgeable and mixed mode operation
for use in various systems, including those with satellite speakers and/or
subwoofers
• Variable high-pass/low-pass electronic crossover with a 12dB per octave
slope and full adjustable range (from 55Hz to 5.5kHz) to aid in audio system
design
• Variable bass boost circuit to reinforce low frequency signals that may be
lost due to subwoofer box design
• Adjustable input level controls with ground loop isolation accepting a wide
range of input signals
• Remote turn-on with "soft start" muting to prevent turn-on "thump"
• Pulse-Width Modulated (PWM) MOSFET power supply with low AM RFI
and protection circuits for overheating and speaker shorts
• 2-ohm load capability to drive a variety of speaker systems
• Gold-plated input/output connectors and an external automotive type fuse
• Aluminum heat sink for efficient heat dissipation
• Low profile, compact size for space limited installations
ABOUT THE MANUAL AND WARRANTY
To start enjoying your new Clarion two-channel amplifier, please read the
instructions listed in this manual. Keep all instructions for future reference.
Please fill out and send in the enclosed warranty card to protect your purchase
and aid in warranty service. Also, save your original sales receipt as proof of
purchase.
TABLE OF CONTENTS
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Input Connections and Audio Controls . . . . . . . . . . . . . . . . . . . . . . . . . 1
Connections for Power and Speakers . . . . . . . . . . . . . . . . . . . . . . . . . 3
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Mounting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wiring Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting the Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting the Crossover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting the Bass Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Final System Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Product Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
