Request:
http://myserver/axis-cgi/param.cgi?action=add
&template=streamprofile
&group=StreamProfile
&StreamProfile.S.Name=myprofile2
StreamProfile.S.Description=My%204CIF%20profile
&StreamProfile.S.Parameters=videocodec%3dh264
%26resolution%3d4CIF%26text%3d1%26textstring%3d4CIF%2520profile
Response:
S5 OK
Example 3:
Congure a stream prole. In this example the prole is named myprofile and the Parameters string contains the following
arguments: resolution=CIF, text=1 and textstring=CIF prole. See2.7 Image RequestArguments, on page13 what
arguments that could be used in the Parameters string.
Note
Characters in the Parameters string must be URL-encoded, so
resolution=CIF&text=1&textstring=CIF%20profile becomes
resolution%3dCIF%26text%3d1%26textstring%3dCIF%2520profile.
The blank space is encoded as %20, the equal sign (=) as %3d, the ampersand (&) as %26 and the percent sign is encoded
as %25.
Request:
http://myserver/axis-cgi/param.cgi?action=update
&StreamProfile.S4.Name=myprofile
&StreamProfile.S4.Description=My%20CIF%20profile
&StreamProfile.S4.Parameters=resolution%3dCIF%26text%3d1%26textstring%3dCIF%2520
profile
Response:
OK
Example 4:
List the parameters of a stream prole.
Request:
http://myserver/axis-cgi/param.cgi?action=list&group=StreamProfile.S5
Response:
root.StreamProfile.S5.Name=myprofile2
root.StreamProfile.S5.Description=My%204CIF%20profile
root.StreamProfile.S5.Parameters=videocodec%3dh264
%26resolution%3d4CIF%26text%3d1
%26textstring%3d4CIF%2520profile
5.3 Stream Prole Parameters
The parameters in the StreamProfile group control stream prole settings.
