09/9/8 XL-DH229N EN
E-15
As part of our policy of continuous improvement, SHARP
reserves the right to make design and specification
changes for product improvement without prior notice. The
performance specification figures indicated are nominal
values of production units. There may be some deviations
from these values in individual units.
Specifications
Power source
AC 120 V ~ 60 Hz
Power
consumption
45 W
Dimensions
Width: 6-1/2" (165 mm)
Height: 8-2/3" (220 mm)
Depth: 9-1/4" (235 mm)
Weight
8.8 lbs. (4.0 kg)
Output power
RMS: Total 100 Watts (50 Watts per
channel into 4 ohms at 1 kHz, 10%
total harmonic distortion.)
FTC: 37.5 Watts minimum RMS per
channel into 4 ohms from 100 Hz to
20 kHz, 10% total harmonic
distortion.
Output terminals
Speakers: 4 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Video output: 1 Vp-p
Input terminals
Audio In (audio signal):
250 mV/47 k ohms
Type
Single disc multi-play compact disc
player
Signal readout
Non-contact, 3-beam
semiconductor laser pickup
D/A converter
Multi bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range
90 dB (1 kHz)
General
Amplifier
CD player
USB host interface
●
Complies with USB 1.1 (Full
Speed)/ 2.0 Mass Storage
Class.
●
Support Bulk only and CBI
protocol.
Support file
●
MPEG 1 Layer 3
●
WMA (Non DRM)
Bitrate support
●
MP3 (32 ~ 320 kbps)
●
WMA (64 ~ 160 kbps)
Other
●
Maximum total number of
MP3/WMA files is 1024.
●
Maximum total number of
folders is 255 INCLUSIVE of
root directory.
●
The ID3TAG information
supported are TITLE, ARTIST
and ALBUM only.
●
Supports ID3TAG version 1
and version 2.
File system
support
●
Support USB devices with
Microsoft Windows/DOS/FAT
12/FAT 16/ FAT 32.
●
2 kbyte block length for sector.
Frequency range
FM: 87.5 - 108 MHz
AM: 530 - 1,720 kHz
Type
2-way type speaker system
2" (5 cm) tweeter
4" (10 cm) woofer
Maximum input
power
100 W
Rated input power
50 W
Impedance
4 ohms
Dimensions
Width: 5-13/16" (148 mm)
Height: 10-1/4" (220 mm)
Depth: 6-7/16" (163 mm)
Weight
3.60 lbs. (1.63 kg)/each
USB
Tuner
Speaker
