4
GB
About This Manual
The instructions in this manual are for models
STR-DE585, STR-DE485E and STR-DE485. Check
your model number by looking at the lower right
corner of the front panel. In this manual, the
STR-DE585 is used for illustration purposes unless
stated otherwise. Any difference in operation is
clearly indicated in the text, for example,
“STR-DE485E only”.
About area codes
The area code of the receiver you purchased is
shown on the lower portion of the rear panel (see
the illustration below).
Any differences in operation, according to the
area code, are clearly indicated in the text, for
example, “Models of area code AA only”.
Tip
The instructions in this manual describe the controls
on the receiver. You can also use the controls on the
supplied remote if they have the same or similar
names as those on the receiver. For details on the use
of your remote, see
• pages 38-44 for RM-PP506 (STR-DE585 area code
CA only)
• pages 45-48 for RM-U306 (except for STR-DE585
area code CA)
4-XXX-XXX-XX AA
FRONTTER
RL
RL
IMPEDANCE USE 8 – 16
Ω
IMPEDANCE USE 8 – 16
Ω
Area code
Note for the supplied remote
For RM-PP506 (STR-DE585 area code
CA only)
The VIDEO 3, TV/SAT, AUX, PHONO,
AUDIO SPLIT, NIGHT MODE, EQ/TONE,
ON SCREEN, /10, /11, /12, 3RD, 2ND ROOM
and SOURCE buttons on the remote are not
available.
For RM-U306 (STR-DE485E only)
The MULTI CH button on the remote is not
available.
Demonstration Mode
The demonstration will activate the first time you
turn on the power. When the demonstration
starts, the following message appears in the
display:
“NOW DEMONSTRATION MODE IF
YOU FINISH DEMONSTRATION
PLEASE PRESS POWER KEY WHILE
THIS MESSAGE APPEARS IN THE
DISPLAY THANK YOU”
To cancel the demonstration
Press ?/1 to turn the receiver off while the above
message is being displayed. The next time you
turn the receiver on, the demonstration will not
appear.
To view the demonstration
Hold down SET UP and press ?/1 to turn on the
power.
Notes
• Running the demonstration will clear the
receiver’s memory. For details on what will be
cleared, see “Clearing the receiver's memory”
on page 15.
• There will be no sound when the
demonstration mode is activated.
• You cannot cancel demonstration if you did
not press ?/1 while the above message is
being displayed. To cancel demonstration after
the above message appears, press ?/1 twice to
activate the demonstration again. Then, press
?/1 while the above message is being
displayed.
