18
Specifications
Compact disc player
Laser Semiconductor laser (λ = 780 nm)
Emission duration: continuous
Laser output Max 44.6 µW*
* This output is the value measured at
a distance of 200 mm from the
objective lens surface on the Optical
Pick-up block with 7 mm aperture.
Frequency response 2 Hz to 20 kHz ± 1 dB
Signal-to-noise ratio More than 100 dB
Dynamic range More than 88 dB
Harmonic distortion Less than 0.013 %
Channel separation More than 95 dB
Output
LINE OUT
DIGITAL
OUT
(OPTICAL)
General
Power requirements
Where purchased␣
USA/Canada
Australia
Europe
Other countries
Power consumption 12 W
Dimensions (approx.) When the front cover is closed
(w/h/d) 430 × 182.5 × 295 mm (17 × 7 1/4
× 11 5/8 in.) incl. projecting parts
When the front cover is open
430 × 182.5 × 414 mm (17 × 7 1/4
× 16 3/8 in.) incl. projecting parts
Mass (approx.) 5.2 kg (11 lbs 8 oz)
Supplied accessories
Audio cord (2 phono plugs – 2 phono plugs) (1)
CONTROL A1 cord (supplied for Canadian models only) (1)
Remote commander (remote) (1)
Sony SUM-3 (NS) batteries (2)
CD booklet holder (1)
Label (1)
Design and specifications are subject to change without notice.
Troubleshooting
If you experience any of the following difficulties while
using the player, use this troubleshooting guide to help
you remedy the problem. Should any problem persist,
consult your nearest Sony dealer.
There is no sound.
/Check that the player is connected securely.
/Make sure you operate the amplifier correctly.
The CD does not play.
/There is no CD in a slot (“no dISC” appears).
Insert a CD.
/Insert the CD with the label side facing right.
/Clean the CD (see page 17).
/Moisture has condensed inside the player. Open
the front cover and leave the player turned on
for about an hour (see page 17).
The remote does not function.
/Remove obstacles in the path of the remote and
the player.
/Point the remote at the remote sensor g on the
player.
/Replace all the batteries in the remote with new
ones if they are weak.
/Set the CD1/2/3 switch on the remote
according to the position of the COMMAND
MODE selector displayed in the front panel
display (see page 5).
The player functions incorrectly.
/The microcomputer chips may be operating
incorrectly. Disconnect the AC power cord, then
connect it back to the wall outlet to reset the
player.
Load impedance
Over 10 kilohms
Wave length: 660 nm
Maximum
output
level
2 V
(at 50 kilohms)
– 18 dBm
Jack
type
Phono
jacks
Optical
output
connector
Power requirements
120 V AC, 60 Hz
240 V AC, 50 Hz
220 V – 230 V AC, 50/60 Hz
110 V –120 V or 220 V – 240 V
AC, adjustable, 50/60 Hz
