SIR-GM1 Operation and Installation Guide
11
SIR-GM1 Installation Guide
FILTER &
FUSEBOX
OUT
IN
System 2
For vehicles not wired for satellite radio
Connect YELLOW wire to the Battery
Positive or other good B+ source
Factory bus connector
(removed from headunit)
Connect Black wire to the a solid
Chassis Ground (as short as possible)
Factory bus connector
SIR-GM1
Connector
T-Harness
Interface Cable
Power Harness
with Filter
