10
SPECIFICATIONS
FEATURES - Power HX2 DVC
• BART Surround - Santoprene
• Basket - Power LX Cast
• Hyper extended pole piece
• Aero-vent pole piece
Model - Punch HX2 DVC RFD2212 RFD2115 RFD22215 RFD3118
Nominal Impedance (ohms) 4 (2) 2 (2) 4 (2) 2 (2)
Voice Coil Diameter-inch (mm) 3.0 (76.2) 3.0 (76.2) 3.0 (76.2) 4.0 (101.6)
FS (Hz) 29 22 24 24
QTS 0.48 0.453 0.53 0.325
VAS-cu.ft. (liter) 2.65 (75) 6.39 (181) 5.76 (163) 6.41 (182)
Xmax-inch (mm) .55 (14) .55 (14) .55 (14) .74 (19)
SPL (dB @ 1w/1m) 88 88.2 89 90.6
Power Handling (RMS) 500 500 600 1000
Power Handling (Max) 1000 1000 1200 2000
Mounting Dia.-inch (mm) 10-13/16 (275) 13-13/16 (351) 13-13/16 (351) 16-5/16 (414)
Mounting Depth-inch (mm) 5-13/16 (148) 6-15/16 (176) 6-15/16 (176) 9-1/8 (232)
Speaker Dis.-cu. ft. (liter) 0.069 (1.95) 0.109 (3.08) 0.109 (3.08) 0.244 (6.92)
Sealed Box Vol.-cu. ft. (liter) 1.25 (35.4) 2.5 (70.79) 2.5 (70.79) 4.0 (113.28)
Vented Box Vol.-cu. ft. (liter) 2.0 (56.63) 2.5 (70.79) 2.5 (70.79) 5.0 (141.58)
Port Diameter & Length (in.) (1) 4 x 10.75 (1) 4 x 8 (1) 4 x 8 (3) 4 x 8.75
Port Diameter & Length (cm) (1) 10.2 x 27.3 (1) 10.2 x 20.32 (1) 10.2 x 20.32 (3) 10.2 x 22.23
Model - Punch HX2 DVC RFD3218 RFR3110 RFR3112 RFR3115
Nominal Impedance (ohms) 4 (2) 2 (2) 2 (2) 2 (2)
Voice Coil Diameter-inch (mm) 4.0 (101.6) 4.0 (101.6) 4.0 (101.6) 4.0 (101.6)
FS (Hz) 24 28 26 22
QTS 0.451 0.313 0.338 0.388
VAS-cu.ft. (liter) 7.03 (199) 0.60 (17) 1.46 (41) 4.45 (126)
Xmax-inch (mm) .74 (19) .74 (19) .74 (19) .74 (19)
SPL (dB @ 1w/1m) 89.4 83 85 87.5
Power Handling (RMS) 1000 1000 1000 1000
Power Handling (Max) 2000 2000 2000 2000
Mounting Dia.-inch (mm) 16-5/16 (414) 9-3/16 (234) 10-13/16 (275) 13-13/16 (351)
Mounting Depth-inch (mm) 9-1/8 (232) 6-11/16 (170) 7-1/16 (180) 8-3/16 (208)
Speaker Dis.-cu. ft. (liter) 0.244 (6.92) 0.115 (3.25) 0.127 (3.60) 0.185 (5.23)
Sealed Box Vol.-cu. ft. (liter) 4.0 (113.28) 0.625 (17.7) 1.0 (28.32) 1.25 (35.4)
Vented Box Vol.-cu. ft. (liter) 5.0 (141.58) 1.75 (49.56) 2.5 (70.8) 3.5 (99.11)
Port Diameter & Length (in.) (3) 4 x 8.75 (3) 3 x 16.5 (2) 4 x 12.65 (4) 4 x 18
Port Diameter & Length (cm) (3) 10.2 x 22.23 (3) 7.6 x 41.91 (2) 10.2 x 32.13 (4) 10.2 x 45.72
Number of ports noted in ( )
Number of ports noted in ( )
Specifications subject to change without notice
Model - Power HX2 DVC
