Congratulations on your purchase and
welcome to Philips!
To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Supplied Accessories
– AC power cord
Top/front panels (See 1)
1
DBB
–
turns the bass enhancement on/off
2
TUNING
– tunes to radio stations
3 PUSH TO OPEN
– opens/closes the CD
door
4
Source selector: CD/USB, FM, MW, OFF
–
selects CD, USB or radio (FM/MW) source
–
switches off the set
5
VOLUME
–
adjusts volume level
6
Display
–
shows the CD/USB functions.
7
CD/USB – enters disc or USB mode
8
REPEAT
–
repeats a track / CD program /
entire CD.
9
USB port
– connects an external USB mass
storage device
.
0
2 ;
–
starts or pause CD/USB playback
∞ §
–
selects the next/previous track
– searches forwards/backwards (press
and hold the button) within the cur-
rent track
9
–
stops disc/USB playback;
–
erases a program
! PROG – programs tracks and reviews the
program
@
ALB +/-
– For MP3-CD/USB only: select
albums.
#
SHUFFLE –
plays all tracks in random order
.
Back/bottom panel (See 1)
$
MP3 LINK
– inlet for external audio source
.
%
AC MAINS~ - inlet for power cord.
^
Voltage selector - adjusts to match the
local voltage: 110-127V or 220-240V.
& Telescopic antenna - improves FM recep-
tion.
*
p
- 3.5 mm stereo headphone socket
Helpful hints: The speakers will be muted
when headphones are connected to the set.
(
Battery door –
Press on the arrow and
push to
insert 6 x 1.5V R20/ UM1/ D-cells.
CAUTION
– Visible and invisible laser radia-
tion. If the cover is open, do not
look at the beam.
– High voltage! Do not open.You
run the risk of getting an electric
shock. The machine does not con-
tain any user-serviceable parts.
– Modification of the product
could result in hazardous radiation
of EMC or other unsafe operation.
English Controls
