Precautions
1. Recording Copyright—Unless it’s for personal use
only, recording copyrighted material is illegal without
the permission of the copyright holder.
2. AC Fuse—The AC fuse inside the unit is not user-
serviceable. If you cannot turn on the unit, contact
your Onkyo dealer.
3. Care—Occasionally you should dust the unit all over
with a soft cloth. For stubborn stains, use a soft cloth
dampened with a weak solution of mild detergent and
water. Dry the unit immediately afterwards with a
clean cloth. Don’t use abrasive cloths, thinners,
alcohol, or other chemical solvents, because they may
damage the finish or remove the panel lettering.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SECTION
CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the unit’s rear panel
(e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).
The power cord plug is used to disconnect this unit
from the AC power source. Make sure that the plug is
readily operable (easily accessible) at all times.
For models with [POWER] button, or with both
[POWER] and [ON/STANDBY] buttons:
Pressing the [POWER] button to select OFF mode
does not fully disconnect from the mains. If you do
not intend to use the unit for an extended period,
remove the power cord from the AC outlet.
For models with [ON/STANDBY] button only:
Pressing the [ON/STANDBY] button to select
Standby mode does not fully disconnect from the
mains. If you do not intend to use the unit for an
extended period, remove the power cord from the AC
outlet.
Placement
The subwoofer cabinet is made out of wood and is
therefore sensitive to extreme temperatures and
humidity, do not put it in locations subject to direct
sunlight or in humid places, such as near an air
conditioner, humidifier, bathroom, or kitchen.
Do not put water or other liquids close to the subwoofer.
If liquid is spilled over the subwoofer, the drive units
may be damaged.
Subwoofer should only be placed on sturdy, flat surfaces
that are free from vibration. Putting it on uneven or
unstable surfaces, where it may fall and cause damage,
will affect the sound quality.
• Subwoofer is designed to be used in the upright vertical
position only. Do not use it in the horizontal or tilted
position.
If the subwoofer is used near a turntable, CD player or
DVD player, howling or slipping of sound may occur.
To prevent this, move it away from the turntable, CD
player or DVD player, otherwise lower the unit’s output
level.
Connection
With other audio-video components, connect the
subwoofer’s LINE INPUT to the subwoofer pre out jack
of your equipment. Never plug any kind of musical
instrument to the subwoofer.
Supplied Accessories
Power cords
(The plug type varies from country to country. From the
two supplied power cords, choose the one whose plug
matches the type of your AC wall outlet.)
• Pin connector cable 3 m
4 floor pads for the subwoofer
*
In catalogs and on packaging, the letter added to the end of the
product name indicates the color of the
SKW-770.
Specifications and operation are the same regardless of color.
Using the Floor Pads for Subwoofer
If the subwoofer is placed
on a hard floor (wood,
vinyl, tile, etc.) and
playback is very loud, the
subwoofer’s feet may
damage the flooring.
To prevent this, place the supplied pads underneath the
subwoofer’s feet. The pads also provide a stable base for
the subwoofer.
1.8 m2m
Pad
