ENGLISH
USING THE T 754
You may operate the T 754 receiver from its front panel or via the HTR 2 remote control. Since the remote
will be the primary controller for most cases, we will focus on remote-controlled operations. Be sure also to
read the section, "Front Panel" above.
With the HTR 2’s remote's [Amp] device selected, the remote’s numeric-key section directly selects the
receiver’s inputs, plus the internal tuner ([Tuner), Tape Monitor ([Tape]), and multichannel input ([Ext. 7.1/
5.1]) refer to the red labels directly above each key.
• When an audio-only source (CD, DISC, TUNER) is selected, the most recently-selected video signal
remains selected, until another audio-video input is selected
• When you change sources, the VFL will display the new input in its primary display.
• A newly selected input's listening mode (Stereo, EARS, Pro Logic II, etc.) will revert to the mode to which
it is configured on the <Input Settings> line of the setup menu, unless the incoming signal is a Dolby
Digital or DTS source, in which case the input will be set automatically to the appropriate decoding mode.
Use the HTR 2 remote's <Volume up/down> keys to adjust the "master volume" of the T 754, raising or
lower all channels together. Note that:
• A momentary keypress will change the master volume by 1 dB increments; if you hold down <Volume up/
down> the master-volume change will "run-on" until the key is released.
• The T 754's OSD will show the volume setting as a line graphic with a numeric display above in dB relative
to the reference level.
Since recordings vary considerably in overall average level, there is no imperative to listen at any particular
master-volume setting. A setting of -20 may sound "as loud" from one CD or DVD as -10 does from another.
• If muting has been activated (below), adjusting master-volume via the HTR 2 remote or the front-panel
knob automatically releases the mute function.
• The T 754 will power-up from Standby mode at whatever master volume setting was last used; however,
if the prior setting was greater than –20 dB the T 754 will power up to –20 dB. This prevents inadvertently
beginning a session at excessive volume.
MUTING THE SOUNDMUTING THE SOUND
MUTING THE SOUNDMUTING THE SOUND
MUTING THE SOUND
Use the HTR 2 remote's <Mute> key to silence all channels completely. Muting is always available,
regardless of source or listening mode selections. Note that:
• Cycling through Standby or powering off does release muting; the T 754 will return from Standby with
muting off if Standby was invoked with muting on.
• Changing input or listening-mode selections does not release muting.
• Adjusting the master-volume upward via the HTR 2 or the front-panel knob automatically releases the
mute function.
The T 754’s internal AM/FM tuner offers very high quality sound from radio broadcasts. Note that reception
and sound quality will always be dependent to a degree on the type of antenna(s) used, as well as proximity
to the broadcast origin, geography, and weather conditions.
ABOUT ANTENNASABOUT ANTENNAS
ABOUT ANTENNASABOUT ANTENNAS
ABOUT ANTENNAS
The supplied ribbon-wire FM antenna can be connected to the rear-panel FM-antenna input using the
‘balun’ included adapter, and should be fully extended to form a “T”. This folded-dipole antenna will usually
work best oriented vertically, with the arms of its “T” full outstretched and arranged perpendicular to the
origin of the desired broadcast. There are no ‘rules,’ however, and experimenting freely with antenna
placement and orientation may yield the clearest sound and lowest background noise. In areas of poor FM
reception, an exterior FM antenna can improve performance dramatically. If radio listening is important to
you, consider consulting an antenna installation professional to optimize your system.
The supplied AM ‘loop’ antenna will usually provide adequate reception. However, an exterior AM antenna
can be used to improve reception; consult an antenna professional for more information.
SELECTING SOURCESSELECTING SOURCES
SELECTING SOURCESSELECTING SOURCES
SELECTING SOURCES
ADJUSTING THE VOLUMEADJUSTING THE VOLUME
ADJUSTING THE VOLUMEADJUSTING THE VOLUME
ADJUSTING THE VOLUME
LISTENING TO RADIOLISTENING TO RADIO
LISTENING TO RADIOLISTENING TO RADIO
LISTENING TO RADIO
