PRE-AMP SECTION
Phono input
Input impedance
(R and C) 47kΩ / 100pF
Input sensitivity, 1kHz MM 2.7mV ref. 0.5V
MC 180µV
Signal/Noise ratio
(A-weighted with cartridge connected) MM 75dB ref. 5mV
MC 73dB ref. 0.5mV
RIAA response accuracy
(20Hz - 20kHz) ±0.5dB
Line level inputs
Input impedance
(R and C) 20kΩ / 220pF
Input sensitivity
(ref. 1W) 180mV
Maximum input signal >25V
Signal/Noise ratio
(A-weighted ref 1W) 90dB
Frequency response 20Hz - 20kHz / ±0.5dB
POWER AMP SECTION
Continuous output power into 8Ω * 25W (14dBW)
Rated distortion
(THD 20Hz - 20kHz) 0.02%
Clipping power
(maximum continuous power per channel) 30W
IHF Dynamic headroom at 8Ω +3dB
IHF dynamic power
(maximum short term power per channel) 8Ω 50W
4Ω 55W
2Ω 70W
Input impedance 11kΩ
Input sensitivity
(for rated power into 8Ω) 1V
Frequency response 10Hz - 70kHz
THD
(20Hz - 20kHz) <0.02%
Remote No
NAD Link No
PHYSICAL SPECIFICATIONS
Dimensions
(W x H x D) 420 x 96 x 240mm
Net weight 5.3kg
Shipping weight 6.7kg
Power consumption
(120 ~ 240V, 50/60Hz) 150VA
* Minimum power per chnnel, 20Hz - 20kHz, both channels driven with no more than rated distiortion.
Dimensions are of unit’s cabinet without attached feet; add up to 18mm for total height.
Dimension depth excludes terminals, sockets, controls and buttons.
© NAD Electronics. All rights reserved. E & OE
