PRE-AMP SECTION
Phono input
Input impedance
(R and C) MM 47kΩ / 200pF
MC 100Ω / 1000pF
Input sensitivity, 1kHz MM 1.3mV ref. 0.5V
MC 60µV ref. 0.5V
Input overload at 20Hz / 1kHz / 20kHz MM 20 / 200 / 2000mV
MC 1.0 / 10 / 100 mV
Signal/Noise ratio
(A-weighted with cartridge connected) MM 80dB ref. 5mV
MC 78dB ref. 0.5mV
THD
(20Hz - 20kHz) <0.02%
RIAA response accuracy ±0.3dB
(20Hz - 20kHz)
Line level inputs
Input impedance
(R and C) 100kΩ / 220pF
Input sensitivity ref. 0.5V 80mV
Maximum input signal 12V
Signal/Noise ratio
(A-weighted ref 0.5V) >100dB
Frequency response ±0.3dB
Line level outputs
Output impedance Normal 50Ω
Tape or EPL 1kΩ
High Level 100Ω
Phones 70Ω
Maximum output level Tape, Normal & EPL 12V
High & headphones 15V
Tone controls
Treble ±12dB at 3, 6, or 12kHz
Bass ±12dB at 50, 120 or 250Hz
Bass EQ +3dB at 55Hz
+6dB at 36Hz
Infasonic filter
(switchable) -3dB at 14Hz, 18dB/octave
Remote No
NAD Link No
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 435 x 84 x 273mm
Net weight 4.3kg
Shipping weight 5kg
Power consumption (120 ~ 240V, 50/60Hz) 20W
Dimensions are of unit’s cabinet without attached feet; add up to 18mm for total height.
Dimension depth excludes terminals, sockets, controls and buttons.
