A3.2 CD Instructions for Use Page 17 of 17
SPECIFICATIONS
:
Issue 6: March 2003
DAC architecture 24 bit Delta-Sigma (Bitstream)
Dual differential
8x oversampling
Disc mechanism Sony
Upsampling 96kHz
Frequency response 10Hz to 20kHz +0 / -0.2 dB
Signal / noise ratio > 115dB 'A' weighted
Total harmonic distortion < 0.006% 10Hz to 20kHz
Total correlated jitter < 170 pS
Channel separation > 100dB 20Hz to 20kHz
Linearity < 0.2dB down to -90dB
Audio output at digital 0dB level 2.14VRMS at 1kHz nominal
Analog output 1 pair RCA connectors
Analog output impedance 50 Ohms
Digital outputs 1 optical (Toslink),
1 S/PDIF (RCA connector)
Power requirements 100 / 115 / 230V AC 50 / 60Hz (factory preset)
15 Watts
Dimensions (approximate) 440mm, 17.3 inches wide
102mm, 4 inches high including feet
375mm, 14.8 inches deep including terminals
Weight 6kg, 13.2lbs unit only, un-boxed
8kg, 17.6lbs in shipping carton
Standard accessories Remote control handset (universal type),
2 batteries (type SUM-4, AAA, LR03)
IEC type mains lead
Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice.
A3.2 CD
Upsampling 24 Bit Compact Disc Player
