Kenwood CD-206 Stereo System User Manual



23
CD-206/204/203/DPF-R6010/R4010/R3010 (En)
Timer operations
Timer playback of CD can be started at any time using an
audio timer which is available in audio stores.
1
Turn the powers of the associated components
ON.
2
Preparation
Load a disc in the CD player. 9
Set the amplifier volume.
3
1
Play the disc.
Set the timer ON time.
4
Set the timer so that it supplies
power at the specified time.
Turn OFF the power output from the audio
timer.
5
÷With some audio timer models, the power is automatically turned OFF
when the timer ON time is set. With such a model, skip step 5 below.
Notes
Notes
1. Some amplifiers cannot be used with a timer. Before using a amplifier, check it.
2. When operating the unit other than CD player using an audio timer, be sure to remove the disc from the CD player.
÷If the amplifier is not connected to the CD player through a system
control cord, select the "CD" input with the input selector.
Preparation
÷ Connect the power cords of the associated
components so that their power can be
turned ON through the audio timer.
(Also, be sure to read carefully the instruc-
tion manual of the timer.)
This unit
System control cord Audio cord
Amplifier
Audio timer
To wall AC outlet
Label side
Adjusting the volume:
Set the volume the maximum (0 dB) using the OUTPUT
(UP) key on the remote control unit (Except CD-203/DPF-
R3010) , and adjust the volume to the desired level on the
amplifier side.
(Since the sound output is at the maximum level when the power
is turned on, lowering the level with the remote control unit will
change the volume.)
Note
Note
÷When the set time comes, the disc playback starts automatically.
÷Do not touch the ON/STANDBY (POWER/
) switches of the
amplifier and CD player.
2
Adjust the amplifier volume.
(Use the remote control unit (Except CD-
203/DPF-R3010) of this unit to adjust the
volume to the maximum level.)
3
Stop the disc.
6
7
12 : 00
