Gemini 36 Turntable User Manual



PS-626x
10” 3-Channel Stereo Mixer
10” 6 line 3 channel mixer with 2 convertible Phono/Line RCA inputs
Rotary gain channel control
3 band rotary EQ per channel with -30db cuts
User-replaceable Rail Glide™ Crossfader
Crossfader Curve and reverse controls
¼” (6.35 mm jack) Mic input with volume control and 2 band EQ
¼” (6.35 mm jack) Headphone output
RCA Master and Record outputs
iPod™ Friendly cable included in package
Dimensions: 10 x 12 x 3.3” (254 x 304 x 84 mm)
Weight: 6.1 lbs (2.76 kg)
PS-424x
10” 2-Channel Stereo Mixer
10” 4 line 2 channel mixer with 2 convertible Phono/Line RCA inputs
Rotary gain channel control
3 band rotary EQ per channel with -30db cuts
User-replaceable Rail Glide™ Crossfader
Crossfader Curve and reverse controls
VU meters with Master/Cue option
Rotary CUE/PGM Fader
¼” (6.35 mm jack) Mic input with volume control and 2 band EQ
¼” (6.35 mm jack) Headphone output
RCA Master and Record outputs
iPod™ Friendly cable included in package
Dimensions: 10 x 12 x 3.3” (254 x 304 x 84 mm)
Weight: 6.08 lbs (2.75 kg)
PS-121x
6.5” 2-Channel Stereo Mixer
6.5” 2 channel mixer with 2 Line / 2 Phono RCA inputs
Rotary gain control
2 band rotary EQ control
Rotary Cue knob for easy cue preview
Rotary Cue volume control
¼” (6.35 mm jack) Mic input with volume control
¼” (6.35 mm jack) Headphone output
iPod™ Friendly cable included in package
Dimensions: 6.5 x 10 x 3.3” (165 x 254 x 84 mm)
Weight: 3.28 lbs (1.72 kg)
Mixers
11
“I never gig without my Gemini PS-626x Mixer. Easy-to-use and
built-to-last, the PS-626x lives up to its predecessors’ reputation.”
DJ Hana
DJ / Producer (USA / Europe)
