4
5. Choose measurement: pH, ORP, or Redox.
6. Choose preamplifier location. Select Xmtr to use the integral preamplifier in the
transmitter; select Sensor/JBox if your sensor has an integral preamplifier or if
you are using a remote preamplifier located in a junction box.
7. Choose temperature units: °C or °F.
8. To change output settings, to scale the 4-20 mA output, to change measure-
ment-related settings from the default values, and to set security codes, press
MENU. Select Program and follow the prompts. Refer to the appropriate menu
tree (page 11).
9. To return the transmitter to default settings, choose ResetAnalyzer in the
Program menu.
Measure?
ppHH
Redox ORP
Use Preamp in?
XXmmttrr
Sensor/JBox
Temperature in?
CC
F
1. Refer to page 5 for installation instructions.
2. Wire pH or ORP sensor to the transmitter. See Figure 6 for panel mount; Figure 7 for pipe or surface mount. Refer
to the sensor instruction sheet for details.
3. Once connections are secure and verified, apply power to the transmitter.
4. When the transmitter is powered up for the first time, Quick Start screens appear. Using Quick Start is easy.
a. A blinking field shows the position of the cursor.
b. Use the ⇐ or ⇒ key to move the cursor left or right. Use the ⇑ or ⇓ key to move the cursor up or down or to
increase or decrease the value of a digit. Use the ⇑ or ⇓ key to move the decimal point.
c. Press ENTER to store a setting. Press EXIT to leave without storing changes. Pressing EXIT also returns the
display to the previous screen.
QUICK START GUIDE
FOR MODEL SOLU COMP Xmt-P-FF/FI TRANSMITTER
