Basic Operations
English
13
DXZ675USB
3-1. Push the [
P.CH
] button upward or
downward to adjust the gain, the FREQ
(center frequency) and the Q.
BASS GAIN
: +7 to –7 (The factory default
setting is “
0
”)
BASS FREQ
: 50Hz/80Hz/120Hz (The
factory default setting is “
50
”)
BASS Q
: 1/1.25/1.5/2 (The factory default
setting is “
1
”)
3-2. Press the [ ] button to return to the
previous mode.
●
Adjusting the treble
The treble gain and treble FREQ (center
frequency) can be adjusted as follows.
The adjustment can only be performed when
the DZE is set to “
DZE OFF
”.
2-1. Select “
TREBLE
”.
2-2. Press the [ ] button.
2-3. Push the [
SEEK PANEL
] leftward or
rightward and select from:
“
TREB GAIN
”
↔
“
TREB FREQ
”
3-1. Push the [
P.CH
] button upward or
downward to adjust the gain and FREQ
(center frequency).
TREB GAIN
: +6 to –6 (The factory default
setting is “
0
”)
TREB FREQ
: 8KHz/12KHz (The factory
default setting is “
12K
”)
3-2. Press the [ ] button to return to the
previous mode.
●
Adjusting the sound restorer
The sound restorer enriches the playback of all
types of music files that have undergone any
level of data compression.
2-1. Select “
S RESTORER
”.
3-1. Push the [
P.CH
] button upward or
downward to adjust.
Each time you push the [
P.CH
] button, the
sound restorer changes in the following
order:
“
OFF
”
↔
“
1
”
↔
“
2
”
↔
“
3
”
∗
The factory default setting is “
OFF
”.
Set this adjustment in accordance with the
music source used
OFF:
For music sources compressed at
high bit rate
1:
For music sources compressed for high
quality at low bit rate
2:
For music sources compressed for
standard quality at low bit rate
3:
For music sources compressed for low
quality at low bit rate
●
Setting high pass filter
2-1. Select “
HPF
”.
3-1. Push the [
P.CH
] button upward or
downward to select the setting. Each time
you push the [
P.CH
] button, the setting
changes in the following order:
“
THRGH” ↔ “50Hz” ↔ “80Hz” ↔ “120Hz”
∗ The factory default setting is “THRGH”
(through).
● Setting low pass filter
2-1. Select “S-W LPF”.
3-1. Push the [P.CH] button upward or
downward to select the setting.
Each time you push the [P.CH] button, the
setting changes in the following order:
“THRGH” ↔ “50Hz” ↔ “80Hz” ↔ “120Hz”
∗ The factory default setting is “THRGH”
(through).
● Adjusting the balance
2-1. Select “BALANCE”.
3-1. Push the [P.CH] button upward to
emphasize the sound from the right
speaker, push the button downward to
emphasize the sound from the left speaker.
∗ The factory default setting is “0”.
(Adjustment range: L12 to R12)
● Adjusting the fader
2-1. Select “FADER”.
3-1. Push the [P.CH] button upward to
emphasize the sound from the front
speaker, push the button downward to
emphasize the sound from the rear
speaker.
∗ The factory default setting is “0”.
(Adjustment range: R12 to F12)
