280-8007-00
DXZ448R 13
English
“Z+ OFF” ➜ “B-BOOST” ➜ “IMPACT” ➜
“EXCITE” ➜ “CUSTOM” ➜ “Z+ OFF” ...
• B-BOOST : bass emphasized
• IMPACT : bass and treble
emphasized
• EXCITE : bass and treble
emphasized mid de-
emphasized
• CUSTOM : user custom
• Z+ OFF : no sound effect
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
●When “B-BOOST” is set
“B-BOOST” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode
●When “IMPACT” is set
“IMPACT” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode
●When “EXCITE” is set
“EXCITE” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode
●When “CUSTOM” is set
“BASS” ➜ “TREBLE” ➜ “BAL 0” ➜ “FAD 0”
➜ Last function mode
●When “Z+ OFF” is set
“BAL 0” ➜ “FAD 0” ➜ Last function mode
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1.
Press the [A-M] button and select “BASS”.
2. Turning the [ROTARY] knob clockwise
emphasizes the bass; turning it
counterclockwise attenuates the bass.
∗ The factory default setting is “B
<
G 0
>
”.
(Adjustment range: –6 to +6)
3. Press the [a] or [d] button to select
“B
<
F 60
>
”.
Tu rning the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗ The factory default setting is “B
<
F 60
>
”.
(Adjustment 60/100/200 Hz)
4.
Press the
[a] or [d]
button to select “B
<
Q 1
>
”.
Tu rning the [ROTARY] knob clockwise or
counterclockwise to select the Q-curve.
∗ The factory default setting is “B
<
Q 1
>
”.
(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1.
Press the [A-M] button and select “TREBLE”.
2. Turning the [ROTARY] knob clockwise
emphasizes the treble; turning it
counterclockwise attenuates the treble.
∗ The factory default setting is “T
<
G 0
>
”.
(Adjustment range: –6 to +6)
3. Press the [a] or [d] button to select
“T
<
F 10
>
”.
Turning the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗ The factory default setting is “T
<
F 10
>
”.
(Adjustment 10 kHz/15 kHz)
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the balance
1. Press the [A-M] button and select “BAL 0”.
2. Turning the [ROTARY] knob clockwise
emphasizes the sound from the right
speaker; turning it counterclockwise
emphasizes the sound from the left speaker.
∗ The factory default setting is “BAL 0”.
(Adjustment range: L13 to R13)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the fader
1. Press the [A-M] button and select “FAD 0”.
2. Turning the [ROTARY] knob clockwise
emphasizes the sound from the front
speakers; turning it counterclockwise
emphasizes the sound from the rear
speakers.
∗ The factory default setting is “FAD 0”.
(Adjustment range: F12 to R12)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Basic Operations
