DXZ435 19
English
Operations Common to Each Mode
Setting the clock
1. Press and hold the [TITLE] button for 1
second or longer to switch to the adjustment
selection display.
2. Press the [a] or [d] button to select
“CLOCK”.
3. Press the [ ] button.
4. Press the [a] or [d] button to select the
hour or the minute.
5. Turn the [ROTARY] knob clockwise or
counterclockwise to set the correct time.
∗ The clock is displayed in 12-hour format.
6. Press the [ ] button to store the time into
memory.
7. Press the [TITLE] button to return to the
previous mode.
Note:
• You cannot set the clock when it is displayed with
only the ignition on. If you drain or remove the
car’s battery or take out this unit, the clock is
reset. While setting the clock, if another button or
operation is selected, the clock set mode is
canceled.
Entering titles
Titles up to 8 characters long can be stored in
memory and displayed for CD, CD changer and
TV stations. The number of titles that can be
entered for each mode are as follows.
Mode Number of titles
CD mode 50 titles
TV mode 20 titles
CD changer mode Number of titles
DCZ625 connected 100 titles
CDC655Tz connected 100 titles
CDC1255z connected 50 titles
6. Press the [DISP] button to select a character.
Each time you press the [DISP] button, the
character changes in the following order:
Numbers ➜ Symbols ➜ Capital letters ➜
Numbers...
7. Turn the [ROTARY] knob to select the
desired character.
8. Repeat steps 5 to 7 to enter up to 8
characters for the title.
9. Press and hold the [ ] button for 2
seconds or longer to store the title into
memory and cancel title input mode.
Clearing titles
1. Select and play a CD in the CD changer or
tune in to a TV station for which you want to
clear the title.
2. Press the [DISP] button and display the sub.
3. Press the [TITLE] button.
The display switches to the title input display.
4. Press the [BND] button.
5. Press and hold the [ ] button for 2
seconds or longer to clear the title and
cancel title input mode.
AUX function
This system has an external input jack so you
can listen to sounds and music from external
devices connected to this unit.
1. Press the [FNC] button to select the mode
you want to enter a title (CD, CD changer or
TV).
2. Select and play a CD in the CD changer or
tune in to a TV station for which you want to
enter the title.
3. Press the [DISP] button and display the sub.
4. Press the [TITLE] button. The cursor position
flashes.
5. Press the [a] or [d] button to move the
cursor.
