Clarion DRX5675 CD Player User Manual



DRX5675 7
English
6. DCP (Detachable Control Panel)
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the included DCP case to prevent scratches.
We recommend taking the detachable control
panel with you when leaving the car.
Removing the DCP
1. Turn off the power.
2. Press the DCP Release button
1.
*
The DCP is unlocked.
3. Remove the DCP.
Attaching the DCP
Insert the DCP into the right side of the source
unit and press the left side to lock it.
Do not insert the DCP from the left side. Doing so
may damage it.
Storing the DCP in the DCP Case
Hold the DCP, in the orientation as shown in the
figure below, and put it into the supplied DCP
case. (Ensure the DCP is in the correct orienta-
tion.)
The DCP can easily be damaged by shocks. After
removing it, place it in a protective case and be
careful not to drop it or subject it to strong shocks.
When the release button is pressed and the DCP is
unlocked, the cars vibrations may cause it to fall.
To prevent damage to the DCP, always store it in a
protective case after detaching it.
The rear connector that connects the source unit
and the DCP is an extremely important part. Be
careful not to damage it by pressing on it with fin-
gernails, pens, screwdrivers, etc.
Note:
If the DCP is dirty, wipe off with a soft, dry cloth only.
DCP Rear Panel Source Unit Front
Source unit connector
DCP
connector
CAUTION
CAUTION
