Clarion DB346MP CD Player User Manual



xxx-xxxx-xx
DB245 13
English
Loading a CD
Insert a CD into the center of the CD insertion slot
with the labeled side facing up. LOAD" appears in
the display, the CD enters into the slot and start play-
ing.
CD Mode Operations
Notes:
Do not put your hand, fingers, or foreign objects
into the CD insertion slot.
If a CD has already been loaded, another CD
cannot be inserted. Do not insert another one
forcefully.
Discs not bearing the mark cannot be played
with the unit. CD-ROMs cannot be played.
Some CDs recorded in CD-R/CD-RW mode may
not be usable.
Listening to the Disc already Inserted
Press the [FNC] button to select the CD mode,
the CD will start playing.
Stopping (pausing) Playback
While the CD playing pressing the [s] button
will stop the CD and PAUSE indicate.
Press the [s] button again to resume play-
back.
Ejecting the CD
Press the [Q] button, then the CD will be
ejected.
Note:
If the ejected CD is left as it is, it will be reloaded
after 15 seconds.
However, single CDs will not be reloaded, so
make sure to remove them.
Top Function
Press the [BND] button, then the CD will start
playing from the first song (track number 1).
CD SLOT
onds or longer.
Recalling ISR
Press the [ISR] button and the display will show
"ISR". Then the radio station previously memo-
rized will be selected. Press the [ISR] button
again to disengage the unit from the Recalling
ISR function.
Area Change
Use this function when you are using the car
stereo anywhere outside the U.S.
Switchable frequency spacing
This car stereo is initially set to tune in fre-
quency intervals of 10 kHz for AM and 200 kHz
for FM, the standard calibrations inside the U.S.
When using the unit outside the U.S., use the
following procedure to switch the frequency
range.
The table below lists the frequency specifica-
tions for the U.S. and other countries.
Switching the area change
Outside U.S. (New Setting)
While pressing the [AM] button, press the [RPT]
button, then "outside U.S." will be selected.
Inside U.S. standard (Initial Setting)
While pressing the [AM] button, press the [SCN]
button, then the "U.S. standard" will be selected.
Radio Operations
New Setting
(outside U.S.)
9 kHz
Initial Setting
(U.S. Standard)
10 kHz
Frequency
spacing
Frequency
range
Frequency
spacing
Frequency
range
AM
FM
531 to
1,629 kHz
50 kHz
87.0 to
108 MHz
530 to
1,710 kHz
200 kHz
87.9 to
107.9 MHz
