11 CZ309
Basic Operations
●Adjusting the subwoofer output
volume
You can adjust the volume output from the unit’s
subwoofer output terminal.
This adjustment can be performed only when
the “S-W LPF” is set to “LPF 120”, “LPF 80” or
“LPF 50”.
2-1. Select “S-W VOL”.
3-1. Press the [w] or [z] button to increases
or decreases the subwoofer volume.
∗ The factory default setting is “0”.
(Adjustment range: +6 to –6)
∗ When the volume level is more than 30, the
subwoofer volume adjustment value can not
reach +6.
●Adjusting the high pass filter
2-1. Select “HPF”.
3-1. Each time you press the [w] or [z] button
to select the setting.
The setting changes in the following order:
“120” ↔ “THROUGH”
∗ The factory default setting is “THROUGH”
(through).
∗ This is supported only with amplifiers
equipped with this function. Output is not
supported from RCA cables.
Note:
• During SOUND adjustment mode, if no operation
is performed for more than 10 seconds, this
mode can be cancelled and return to previous
mode.
Setting the MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low frequencies like the normal sound
adjustment function, but emphasizes the deep
bass frequencies to provide you with a dynamic
sound.
∗ The factory default setting is “OFF” (off).
1. Press and hold the [SOUND] button for 1
second or longer to turn on the MAGNA
BASS EXTEND effect. “M-B EX” appears in
the display for 2 seconds.
2. Press and hold the [SOUND] button for 1
second or longer to turn off the MAGNA
BASS EXTEND effect.
Radio Operations
Listening to the radio
1. Press the [SRC] button and select the radio
mode.
2. Press the [BND] button and select the radio
band. Each time the button is pressed, the
radio reception band changes in the
following order:
F1 (FM1) ➜ F2 (FM2) ➜ F3 (FM3) ➜ AM ➜
F1 (FM1)...
Tuning
There are 3 types of tuning mode available,
seek tuning, manual tuning and preset tuning.
Seek tuning
1. Press the [BND] button and select the
desired band (FM or AM).
∗ If “MANU” is lit in the display, press and hold
the [BND] button for 1 second or longer.
“MANU” in the display goes off and seek
tuning is now available.
2. Press the [x] or [v] button to
automatically seek a station.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
● Quick tuning
Press and hold the [x] or [v] button for 1
second or longer to tune in a station.
● Step tuning
Press the [x] or [v] button to manually tune
in a station.
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) exists to store individual radio
stations in memory. Press the corresponding
[DIRECT] button or the [w] / [z] button to
recall the stored radio frequency automatically.
Manual memory
1. Select the desired station with seek tuning or
manual tuning.
DXZ385USB_ENG.book Page 11 Friday, October 17, 2008 1:52 PM
