14 BD216
English
FM Tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 11 dBf
50 dB Quieting Sensitivity: 17 dBf
Alternate Channel Selectivity: 75 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
AM Tuner
Frequency Range: 530 kHz to 1,710 kHz
Usable Sensitivity: 25
µ
V
CD Player
System: Compact disc audio system
Usable Discs: Compact disc
Frequency Response: 10 Hz to 20 kHz (±1 dB)
Signal-to-Noise Ratio: 100 dB (1 kHz) IHF-A
Dynamic Range: 95 dB (1 kHz)
Harmonic Distortion: 0.01%
Audio
Maximum Power Output:
180 W (45 W × 4 ch)
Continuous Average Power Output:
17 W × 4, into 4 , 20 Hz to 20 kHz,1%THD
Bass Control Action (30 Hz): ±13 dB
Treble Control Action (10 kHz): ±12 dB
Line Output (with A/C 1 kHz, 10 k): 1.8 V
General
Power Supply Voltage: 14.4 V DC (10.8 V to 15.6
V allowable), negative ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 (4 to 8 allowable)
Weight: 3.31 lb. (1.5 kg)
Dimensions:
7
(178 mm) Width × 2
(50 mm) Height ×
6
(152 mm) Depth
Notes:
Specifications comply with EIA Standards.
Specifications and design are subject to change with-
out notice for further improvement.
Please make sure when connecting external power
amplifier, that you properly, to the car chassis, ground
the amplifier.
If this is not done, severe damage to the source unit
way happen.
2
2-1/4
7
7-3/8
6
(50 mm)(178 mm)
(58 mm)(188 mm)
(152 mm)
10. SPECIFICATIONS
