DESCRIPTION
The Clarion APX1000.2 two-channel amplifier provides 2x270 watts of power
into a 4 ohm load and 2x525 watts of power into a 2 ohm load. This full
featured model is an excellent choice for a variety of car audio sound system
configurations.
The APX1000.2 uses an unregulated MOSFET power supply for superior
control of output wattage. A toroid-coil transformer yields maximum power
transfer with minimum heat loss. Careful attention to circuit design keeps AM
RFI at low levels, so you won’t hear unwanted noise when the level is cranked
up. Protection circuits safeguard the amplifier when overheating and speaker
shorts or improper load conditions occur.
All connections and controls of the APX1000.2 are on the end panels and are
easy to understand. We use gold-plated RCA and barrier connectors to ensure
the best electrical connection for your system. Included is an external
automotive type fuse that is easy to replace.
INPUT CONNECTIONS AND AUDIO CONTROLS
The front panel of the APX1000.2 contains connections for RCA Inputs, Pass
Through Outputs and Audio Controls as shown below.
The RCAInput and Output Connectors are gold-plated RCA Jacks and are
labeled as LEFT and RIGHT.
3
1. Status LEDs
2. Bass Boost Control
3. Freq (Hz) Selection Control
4. X-Over Frequency Multiplier Switch
5. X-Over Mode Switch
6. X-Over Slope Selection Switch
7. X-Over Bypass Switch
8. Left Gain Control
9. Right Gain Control
10. Input Selection Switch
11. RCAInput Jacks
12. RCAPass Through Outputs
Figure 1-
