SETUP AND CONNECTIONS
Placing your system
The following guidelines are offered as an aid in placing the speakers and the Acoustimass
®
module to provide outstanding performance (Figure 2). Feel free to set up the system where it
is most convenient and provides the sound you enjoy.
Figure 2
Recommended system
placement
3 inches
(8 cm)
minimum
6 inches
(15 cm)
minimum
Acoustimass module
Speakers
Positioning the Acoustimass
®
module
The Acoustimass module functions as the unseen part of the system. When placed under or
behind furniture, for example, it plays an invisible role in producing lifelike sound.
Keep the module:
Positioned on a flat surface.
Within reach of an AC (mains) power outlet.
With the rear of the module at least 3 inches (8 cm) from a wall.
With the front aimed away from the wall to decrease or toward the wall to increase bass.
At least 6 inches (15 cm) from your computer monitor or TV to avoid interference from the
module, which is not magnetically shielded.
Where nothing blocks the openings on the back of the module, which provide ventilation to
prevent overheating during use.
Away from heat sources (radiators, baseboards, quartz heater, etc.).
Resting on the bottom surface, not on the top, a side, or either end (Figure 3).
Figure 3
Module placement
Ventilation openings
