7
TUBE ULTRAGAIN MIC200
+ Since presets cannot cover all possible applications,
experiment with different settings until you find those that
work best for you. Think of presets as the starting points
for your sound configuration.
2.2 Rear panel
Fig. 2.2: The rear panel of your MIC200
The balanced 1/4" TRS INPUT of your MIC200 can be used to
connect your electric guitar, for example. This input is wired
parallel to the XLR input.
Ideally, the balanced XLR INPUT should be used to connect
a microphone.
+ In contrast to its outputs, the MIC200s inputs should
never be used simultaneously!
This is the balanced XLR OUTPUT of your MIC200. Use this
connector to feed the XLR input of your mixing console,
multitrack recorder or power amp.
The balanced 1/4" TRS OUTPUT of your MIC200 can also be
connected to a mixer, recording system or power amp.
+ Please note that you can use the XLR and TRS outputs of
your MIC200 at the same time! Thus, it is possible to
connect the MIC200s output signal to two different devices
simultaneously.
2. CONTROL ELEMENTS
