Video Streaming API
This document is copyright protected and is the property of Axis Communications AB and may not be copied, reproduced or distributed in any way without
the prior written consent of Axis Communications AB.
Returned data after a successful request.
HTTP Code: 200 OK
Content-Type: text/plain
Body:
Video 1 = video
Video 2 = no video
Video 3 = no video
Video 4 = video
The response no video means that there is no analog video signal attached to the physical video input port.
2.5 Bitmap
Support for bitmap images is product-dependent. Use the following command to check supported image formats.
http://myserver/axis-cgi/param.cgi?action=list&group=Properties.Image.Format
Response example:
properties.image.format=jpeg,mjpeg,h264,bitmap
The response shows that the Axis product in the example supports bitmap images.
2.5.1 Bitmap Image Request
The syntax bitmap/image.bmp is used to request a bitmap image.
Access control: viewer
Method: GET
Syntax:
http://<servername>/axis-cgi/bitmap/image.bmp
[?<argument>=<value<[&<argument>=<value>...]]
With the following arguments and values:
Argument Description
Bitmap image arguments.
See 2.7 Image RequestArguments for arguments.
Example 9:
Request a bitmap image from the default video source using default settings.
http://myserver/axis-cgi/bitmap/image.bmp
Example 10:
Request a bitmap image from video source 1 with resolution 320x240.
http://myserver/axis-cgi/bitmap/image.bmp?resolution=320x240&camera=1
2.5.2 Bitmap Image Response
When a bitmap image is requested, the Axis product either returns the specied bitmap image le or an error.
10
