Electrical Connection
This appliance should be properly grounded for your safety. The power cord of this appliance
is equipped with a three-prong plug which mates with standard three prong wall outlets to
minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord
supplied.
Plug the appliance into an exclusive properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and or grounding should be directed toward a certified electrician or an
authorized Avanti Products service center.
Use of extension cords is not recommended.
This appliance requires a standard 115/120-volt, 60Hz electrical outlet with three-prong
ground.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
Reversing the Door Swing of
Your Appliance
This appliance has the capability of either opening the door from the left or right side. The unit
is delivered to you with the door opening from the left side. Should you desire to reverse the
opening direction, please call customer service for reversal instructions.
OPERATING YOUR APPLIANCE
Temperature Control
Your appliance has only one control for regulating the
temperature in the fresh food and the freezer compartment.
The temperature control is located on the upper right hand
side of the fresh food section.
The range of the temperature control is from position"1" the
warmest to "5" the coldest.
The first time you turn the unit on set the temperature control
to “5” or the max-position.
After 24 to 48 hours, adjust the temperature control to the setting that best suites your needs.
The setting of “3” should be correct for home or office appliance use.
Changes of the ambient temperature affect temperature in the interior of the appliance
(choose correct setting of the thermostat knob).
To turn the thermostat off, turn the temperature control to "0".
NOTE:
Turning the temperature control to "0" position stops the cooling cycle but does not shut
off the power to the appliance.
If the unit is unplugged, power lost, or turned off; you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the appliance will not
start.
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.
