Controls on Remote Control
Source Button
Press this button to select the audio source.
Volume Adjustment Buttons
To increase the volume level:
Press the button
To decrease the volume level:
Press the button
Button
Radio mode: Pressing this button will select, in ascending
order, stations programmed into the radio’s presets as
shown below.
...
CD Changer mode: DISC Select (UP) button
Press this button to select a disc in ascending order.
MP3/WMA/AAC mode: Folder Select (UP) button
Press this button to select the folder.
MP3 compatible CD changer mode:
Folder Select (UP) / DISC Select (UP) button
Press this button to select a folder in ascending order. Press
and hold this button to select a disc in ascending order.
iPod mode: Switches Playlist/Artist/Album.
DN Button
Radio mode: SEEK (DN) Button
CD/iPod mode: Press this button to go back to the
beginning of the current track.
/
Button
Press this button to switch between the Play and Pause
modes for CD.
Audio Processor Button
Press the button to activate the external audio processor
mode when the external audio processor is connected.*
1
*
1
For the operation of external audio processor, refer to the Owner’s
Manual of the external audio processor you purchased.
Power Button
Press this button to turn the power on/off.
Band Button
Radio mode: BAND Button
Press this button and the band will change.
Changer mode: To switch the changer.
UP Button
Radio mode: SEEK (UP) button
CD/iPod mode: Press this button to advance to the
beginning of the next track.
Button
Radio mode: Pressing this button will select, in descending
order, stations programmed into the radio’s presets as
shown below.
...
CD Changer mode: DISC Select (DN) button
Press this button to select a disc in descending order.
MP3/WMA/AAC mode: Folder Select (DN) button
Press this button to select the folder.
MP3 compatible CD changer mode:
Folder Select (DN) / DISC Select (DN) button
Press this button to select a folder in descending order.
Press and hold this button to select a disc in descending
order.
iPod mode: Switches Playlist/Artist/Album.
Mute Button
Press this button to lower the volume by 20 dB instantly.
Press this button again to cancel.
Remote Control
