VRX653R 45
English
Installation and Wire
connection manual
1. BEFORE STARTING................................................................45
2. PACKAGE CONTENTS ........................................................... 45
3. GENERAL CAUTIONS ............................................................ 46
4. CAUTIONS ON INSTALLATION .............................................. 46
5. INSTALLING THE MAIN UNIT................................................. 47
6. REMOVING THE MAIN UNIT ..................................................49
7. CAUTIONS ON WIRING ..........................................................49
8. WIRE CONNECTION............................................................... 50
9. SAMPLE SYSTEMS ................................................................52
■ Contents
1. This set is exclusively for use in cars with a
negative ground 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “ ”
terminal before starting. This is to prevent
short circuits during installation. (Figure 1)
1 Main unit
2 Manuals
Owner’s manual & Installation manual
Warranty card
3 Power supply lead
4
Bag for accessories of the main unit (No. 1)
Flat head screw (M5 × 8)............................4
Sems hexagonal bolt (M5 × 8)....................5
5
Bag for accessories of the main unit (No. 2)
Hook plate..................................................2
Cord clamp
Spacer
Special screw
6 Universal mounting bracket
7 Remote control unit
8 Battery
(for remote control unit)
9 Outer Escutcheon
0 DCP Case
1. BEFORE STARTING
2. PACKAGE CONTENTS
VRX653R
Installation and Wire connection manual
