PRE-AMP SECTION
Phono input
Input impedance (R and C) 47kΩ / 100pF
Input sensitivity, (1kHz, ref. rated power) 3.2mV
Signal/Noise ratio (A-weighted with cartridge connected) 76dB ref. 5mV
THD (20Hz - 20kHz) <0.04%
RIAA response accuracy (20Hz - 20kHz) ±0.5dB
Line level inputs
Input impedance (R and C) 15kΩ / 100pF
Input sensitivity (ref. rated power) 160mV
Maximum input signal >10V
Signal/Noise ratio (A-weighted ref 1W) 88dB
Frequency response (20Hz - 20kHz) ±0.5dB
Infrasonic filter -3db at 15Hz, 24dB/octave
THD 0.01%
Line level outputs
Output impedance Pre-amp 600Ω
Tape Source Z + 1kΩ
Phones 220Ω
Maximum output level 12V
Tape 8V
Phones >10V into 600Ω
>500mV into 8Ω
Tone controls
Treble ±7dB at 10kHz
Bass ±10dB at 50Hz
Bass EQ +3dB at 70Hz
+6dB at 40Hz
POWER AMP SECTION
Continuous output power into 8Ω * 40W (16dBW)
Rated distortion (THD 20Hz - 20kHz) 0.03%
Clipping power (maximum continuous power per channel) 50W
IHF Dynamic headroom at 8Ω +6dB
IHF dynamic power (maximum short term power per channel) 8Ω 160W (22dBW)
4Ω 200W (23dBW)
2Ω 250W (24dBW)
Damping factor (ref. 8Ω, 50Hz) >50
Input impedance 22kΩ / 880pF
Input sensitivity (for rated power into 8Ω) 1V
Frequency response 6Hz - 50kHz +0, -3dB
Signal/noise ratio ref. 1W 100dB
ref. rated power 116dB
THD (20Hz - 20kHz) <0.03%
