Logitech UE3500 Headphones User Manual


  Open as PDF
of 2

21
English
Product features
1. Adjustable headband
2. Multi-function button
(power on/o, pairing, play/pause,
answer/reject calls)
3. Volume up
4. Volume down
5. Sculpted ear pads
6. Noise-canceling microphone
7. Battery/wireless status light
8. Charging port
9. USB wireless Nano receiver
10. USB charging cable
简体中文
产品功能
1. 可调节头带
2. 多功能按钮 (开关、模式切换、播放/
暂停、接听/挂断电话)
3. 增大音量
4. 减小音量
5. 人体工学耳垫
6. 具备噪音消除功能的麦克风
7. 电量/无线连接状态指示灯
8. 充电端口
9. 超微型 USB 无线接收器
10. USB 充电连接线
1
2
3
4
5
6
9
10
7
8
Getting started with
Logitech® UE 3500
Wireless Headphones + Mic
3500
Getting started with
Logitech® UE 3500
Wireless Headphones + Mic
®
3500
USB
English
Connect with the USB wireless
Nano receiver
1. Press and hold the Multi-function button
for six seconds to turn the headphones
on. The wireless status light will blink.
2. Plug the USB wireless nano receiver into
your PC USB port.
3. The wireless status light will turn solid
green. The headphones are connected.
简体中文
连接到超微型 USB 无线接收器
1. 开启耳机电源：按住多功能按键6秒，
直至无线状态指示灯开始闪烁。
2. 将超微型USB接收器插入电脑的USB
端口。
3. 无线状态指示灯将变为稳定的绿灯。耳
机已连接。
USB
English
Connect to a Bluetooth®device
First Bluetooth pairing
1. Power on the Bluetooth device (e.g. MP3, mobile phone,
smartphone or tablet) to be paired with the headphones.
Turn on Bluetooth for that device. (Refer to your Bluetooth
device documentation to complete these tasks.)
2. Press for nine seconds the headphone Multi-function button.
The headphone status light blinks rapidly. The headphones
enter pairing mode.
3. In the Bluetooth device menu, select Logitech UE 3500
from the Bluetooth menu. If the Bluetooth device requests a
security code, PIN, or pass code, enter 0000.
4. When the headphone status light turns solid green, a
Bluetooth connection is made.
简体中文
连接到蓝牙® 设备
首次蓝牙配对
1. 打开要与耳机配对的蓝牙设备（例如 MP3、移动电话、智
能手机或平板电脑）的电源。开启该设备的蓝牙。（请参考
蓝牙设备说明书完成这些操作。）
2. 按住耳机多功能按钮 9 秒。耳机状态指示灯将快速闪烁。
耳机开始配对。
3. 从蓝牙设备的蓝牙菜单中选择耳机 Logitech UE 3500。如果
您的蓝牙设备要求安全码、PIN 或通行码，请输入 0000。
4. 耳机状态指示灯变成稳定的绿灯后，即表示蓝牙连接成功。
English
Use the headphones
Listen to music or make an Internet call.
Play/Pause. Tap (press for less than
one second) the Multi-function button to play
or pause an audio track or video clip.
1. Select an audio track or video clip.
2. Tap the Multi-function button to play
the audio track or video clip. Tap the Multi-
function button to pause the track or clip.
3. To adjust volume, use the Volume up
and Volume down controls. When
the maximum volume is reached, the
headphones emit a tone.
Answer an incoming call. Connect
the headphones to a smartphone.
Tap (press for less than one second)
the Multi-function button to answer
an incoming call.
Reject an incoming call. Press for two
seconds the Multi-function button.
End a call. Tap (press for less than
one second) the Multi-function button
to end the call.
Bluetooth and USB wireless Nano receiver indications
Solid Green Bluetooth: A connection is made; your headphones are ready to use.
Nano receiver: A connection is made; your headphones are ready to use.
Flashing green Bluetooth: A rapid blink indicates pairing is achieved; a slower blink
indicates the headphones are connectable, but not yet connected.
Nano receiver: Your headphones and Nano receiver are not connected.
No light Your headphones are powered o.
Battery status
Light Battery Level Description
Red and beeping <10% <30 minutes of talk time left
Flashing amber Headphones charging
Steady amber 100% Charging complete
简体中文
耳机的使用
听音乐或进行网络通话。
播放/暂停。轻按（按下时间不超过
1 秒）多功能按钮播放或暂停音频曲目
或视频片段。
1. 选择音频曲目或视频片段。
2. 轻按多功能按钮播放音频曲目或视
频片段。再次轻按多功能按钮即可暂停
曲目或片段。
3. 要调整音量，请使用“增大音量”
和“减小音量”控制键。达到最大音
量之时，耳机将发出声音提示。
接听来电。将耳机连接到智能手机。
轻按（按下时间不超过 1 秒）多功能按
钮接听来电。
拒绝接听来电。按住多功能按钮 2 秒。
结束通话。轻按（按下时间不超过
1 秒）多功能按钮结束通话。
无线状态指示灯
稳定绿灯
蓝牙：连接已经建立，耳机可以使用。
超微型接收器：连接已经建立，耳机可以使用。
闪烁绿灯
蓝牙：快速闪烁说明接到配对请求；慢速闪烁说明耳机可以连接，
但尚未连接。
超微型接收器：耳机未连接到即插即忘超微型接收器。
无指示灯 耳机电源已关闭。
电池状态
指示灯 电池电量 说明
红灯并有警报声 <10% 剩下不到 30 分钟的通话时间
闪烁黄灯 耳机正在充电
稳定黄灯 100% 充电完毕
3
Connect your UE 3500 Wireless Headphones
为UE3500无线耳机建立连接
Charge your UE 3500 WirelessHeadphones
为耳机充电
English
To charge the headphones, plug the
included USB charging cable into your
headphones and computer (or an optional
USB charger). When the headphone
battery is very low, a full charge can take
up to three hours. But you don’t have to
stop using the headphones because they
charge while you talk or listen to music.
简体中文
要对耳机进行充电，请使用随附的 USB
充电连接线连接耳机和电脑（或可选的
USB 充电器）。在耳机电量极低的情况
下，完全充满电可能需要三个小时。充电
时无需停止使用耳机，因为在通话或聆听
音乐时仍然可以充电。
English
Switch connections
You can only connect your UE3500
headphones to one device at a time.
When switching from the USB wireless
Nano receiver to a Bluetooth device,
remove the USB receiver from your
computer before you connect to your
Bluetooth device.
First, turn o the headphones by holding
the Multi-function button for 4 seconds.
Then, turn the headphones on by pressing
the Multi-function button for 6 seconds,
and follow steps 3 through 4 above
to complete the connection with the
Bluetooth device.
When switching from a Bluetooth device
to the USB wireless Nano receiver, turn o
the Bluetooth option on your Bluetooth
device, plug the USB receiver into
your computer.
简体中文
连接到之前使用的设备
UE3500无线耳机每次仅与一个设备连接。
当从电脑USB无线连接方式切换到蓝牙连
接方式时，请先将超微型USB接收器取
下，按住多功能按键4秒直到耳机关机。
之后，按住多功能按键6秒开启耳机电
源，并参照“首次蓝牙配对”中的第3、4
步完成配对.
当从蓝牙连接方式切换到电脑USB无线连
接方式时，请先关闭设备上的蓝牙功能，
然后插入超微型USB接收器。
快速入门
Logitech® UE 3500
无线耳机 + 麦克风
