Yo u can listen to the audio source even if you do not turn on the headphones, but
the noise-canceling function will not work.
•
When using the headphones only for noise reduction, you do not need to connect
the supplied cord.
FOLDING AND STORING
UP
UP
USING THE HEADPHONES
STEREO HEADPHONES
CASQUE STEREO
AURICULARES ESTÉREO
HA-NC250 -J/C
© 2007 Victor Company of Japan, Limited
Printed in China
LNT0087-001A
1. For your safety...
• Do not disassemble or modify the headphones.
• Do not allow inflammable, water or metallic objects to enter the headphones.
• If you find skin problems where the headphones are in contact with your skin, stop
using the headphones; otherwise, it may cause further inflammation or irritation of
the skin.
• When the air is dry such as in winter, you may feel a static shock when using the
headphones.
• If you get sick while using the headphones, stop using them right away.
• Be sure that your hair or any other objects do not get caught in the headband slider
(adjuster) when adjusting the headband.
2. Avoid using the headphones…
•
in places subject to excessive humidity or dust
•
in places subject to extremely high (over 40°C or 104°F) or low (under 0°C or 32°F)
temperatures
3. DO NOT leave the headphones…
•
exposed to direct sunlight
•
near a heater
4. To protect the headphones, DO NOT…
•
allow them to get wet
•
shake them or drop them onto hard objects
☐ Be careful not to apply power that exceeds the headphones’ input capacity. This may
result in sound distortion and could damage the oscillation board.
☐ Grasp and pull the plug itself to disconnect the headphones. Do not pull out using the cord.
☐ When using the headphones near a cellular phone, noise may occur. Keep the headphones
away from the cellular phone.
☐ The ear pads will wear out earlier than the other parts, even in normal use or in normal
storage due to the characteristics of the material used.
☐ When covering the headphones with an object, the noise-canceling function may not
work well or a howling noise may occur. In this case, take off the object which is covering
the headphones.
BATTERY INSERTION
The battery should be changed when the operation indicator fades or does not turn on.
The noise-canceling function becomes less effective as the battery wears down so be sure
to replace the battery as necessary to maintain the proper performance of the headphones.
L
Left
R
Right
•
Be sure to insert the battery with the positive ª and negative · polarities correctly
positioned.
•
Do not heat, disassemble or short-circuit battery and never dispose of it by throwing it
in a fire.
•
Read the caution on the battery before use.
•
Be sure not to change the battery in a place where there is a lot of dust.
•
Be sure to remove the battery if you are not going to use the headphones for a long time.
Thank you for purchasing this JVC product.
Before you begin operating this unit, please read the operating instructions carefully to be sure you get the best possible performance.
If you have any questions, consult your JVC dealer.
Right housing
English
SPECIFICATIONS
Frequency response 8 Hz – 24, 000 Hz (power — ON)
Noise reduction More than 16.5 dB at 150 Hz
Sensitivity 102 dB/1 mW (power — ON)
100 dB/1 mW (power — OFF)
Input impedance 40 Ω (power — ON), 96 Ω (power — OFF)
Driver unit ϕ40 mm
Power supply AAA battery (DC 1.5 V) x 1
Battery life Approx. 20 hours* (using Manganese AAA battery)
Approx. 50 hours* (using Alkaline AAA battery)
*
Var ies depending on operating conditions.
*
Without ambient noise.
Cord length** 1.2 m (3.9 ft) (detachable)
Mass 150 g (5.30 oz) (incl. battery)
140 g (4.94 oz) (excl. battery)
Accessories Carrying case x 1, Manganese AAA battery (R03) x 1,
Cord**x 1, Dual plug adapter (for in-flight use) x 1,
Stereo phone plug adapter 6.3 mm (1/4 inch) x 1
• Designs and specifications are subject to change without notice.
Use the supplied cord only with these headphones.
Insert the · end first,
then push the battery in.
INSTRUCTIONS
MANUEL D’INSTRUCTIONS
MANUAL DE INSTRUCCIONES
The supplied battery is only for initial use.
Turn off the power before replacing the battery.
THE NOISE CANCELING FUNCTION
The active noise-canceling function does not reduce high frequency noise. It cancels
out noise which mainly consists of low frequencies, such as that from vehicles, air
conditioners, etc.
Notes
Put off the earpad.
Operation indicator
Power switch
To activate the noise-canceling function
Push
Hearing Comfort and Well-Being
• Do not play your personal audio at a high volume. Hearing experts advise against
continuous extended play.
• If you experience a ringing in your ears, reduce volume or discontinue use.
Traffic Safety
• Do not use while operating a motorized vehicle. It may create a traffic hazard and is
illegal in many areas.
• You should use extreme caution or temporarily discontinue use in potentially
hazardous situations.
• Even though your headphones are of the open-air type designed to let you hear outside
sounds, don’t turn up the volume so high that you can’t hear what’s around you.
CAUTION
Misuse of the battery could result in leakage. This could cause a fire or an
explosion. To prevent this, pay special attention to the following points:
[European Union only]
[Union européenne uniquement]
[Sólo Unión Europea]
