10” (25.4cm) DVC SUBWOOFER
Internal Area cu. ft. (liter) 0.5 (14.16) Internal Area cu. ft. (liter) 1.0 (28.32)
-3dB Point (Hz) 51 -3dB Point (Hz) 29
Qtc Enclosure Damping 0.75 Tuning Frequency (Hz) 33
H Height -inch (cm) 13 (33.02) H Height -inch (cm) 13 (33.02)
W Width -inch (cm) 18.5 (46.99) W Width -inch (cm) 24 (60.96)
D Depth -inch (cm) 6.75 (17.15) D Depth -inch (cm) 9.25 (23.50)
P Port Diameter and Length -inch (cm) 3 x 15.25 (7.62x 38.74)
Ported Enclosure RecommendationSealed Enclosure Recommendation
NOTE: Internal volume is measured before speaker and/or port displacement. External dimensions are based on the use of 3/4”
(1.9cm) material. The port can be placed on any fitting face as long as the port ends are not obstructed. When using enclosures
other than recommended, contact technical support or your local installation expert. Proper enclosure design is one of the key
components to subwoofer performance and should be handled by experienced installers. Please contact your authorized Clarion
dealer for the best results.
V
b
V
b
F
3
F
3
F
b
Rigid PP Injection Molded Cone
High Strength Stamped Steel Basket
High Temperature Nomex Spider
Heavy Duty Dual Copper Voice Coil
Dual Stacked 37 oz Strontium Ferrite Magnets
Molded Rubber Front Gasket
High Excursion NBR Surround
Fiber Dust Cap
Aluminumized Composite Dust Cap
9-25/32''DIA
10-21/32''DIA
25/32''
5-15/32''
8-29/32''DIA
Gold Plated Compression Terminal
Formed Top Plate
Rubberized Acoustic Dampener
Kapton Voice
Coil Former
Air Cooling Voice Coil Chamber
Heavy Duty Coated Tinsel Leads
Maximum Musical Input Power 1500W F
o
Resonance Frequency 35Hz
Continuous Input Power 500W V
as
Equivilant Stiffness 18.5L
Sensitivity 82dB Q
ts
Total Electromechanical Dampening 0.65
Impedance 4 ohms + 4 ohms S
d
Cone Area 314.1 cm²
Thiele / Small Electromechanical ParametersElectrical Specifications
