VDH910
VIDEOCASSETTE PLAYER/RECORDER
20
SPECIFICATIONS
General Specifications
Power Requirement: 12 V DC
Power Consumption: 12 watts, Power On
Weight: 5.3 lb (2.4 kg)
Dimensions (w x h x d): 10.4 x 3.7 x 10.2 in.
(265 x 92.5 x 265 mm)
Tape Deck Specifications
Format: VHS 1/2 inch (12.7 mm) Standard
Scanning System: Standard NTSC
Recording System: Rotary Double azimuth four-head
helical scanning system
Video heads: DA-4 rotary heads
Audio heads: Linear; 1 stationary
Hi-Fi; 2 rotary
Control head: 1 stationary
Erase head: 1 full track, 1 audio track
Antenna input/output terminals: UHF/VHF: 75 ohms F-Connector
Recording/playback System: Recording: VHS format (SP, SLP)
Playback: VHS format (SP, LP, SLP)
Record/Play Time: 6 hours with T-120 on SLP speed
FF/REW Time (T-120): Approx. 2 minutes and 20 seconds
Supplied Accessories: IR Remote Control, (1) 5 Meter A/V Cable,
4-pin Power Cable, (8) 3S-M4 Self-Tapping
Screws, (16) 1S-M5 Self-Tapping Screws,
(2) Installation Brackets, and Remote IR
Sensor.
Channel List
On Air 12 VHF (Channels 2-13)
56 UHF (Channels 14-69)
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 16 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particu-
lar installation.
If this equipment does cause harmful interference to radio or television
reception, which can be verified by turning the unit off and on, the user is
encouraged to consult the dealer or an experienced radio/television techni-
cian for help.
