NOTE: Press the MENU button to interrupt the Auto Channel
Memory function.
Channel Add/Delete
TV channels can be added or deleted from the tuner’s memo-
ry using the Channel Add/Delete function.
• Select the Channel Add/Delete function from the Channel
Setup Menu then press the ENTER button.
• Use the CH/TRK UP or DN buttons to select the desired
channel. Press the ENTER button to add the channel, or
press the SHIFT button to delete the channel.
NOTE: The Auto Channel Memory function must be preformed
before the Channel Add/Delete will function.
VCR Output Channel
The VDH910 is equipped with 75 ohm F-Connectors that
allow connection to normal composite video inputs on TVs.
Set the output channel to Channel 3 or Channel 4, whichever
is vacant in your area.
• Select the VCR Output Channel function from the Main
Menu.
• Press the ENTER button to toggle between CH3 or CH4.
OWNER’S MANUAL/INSTALLATION GUIDE
13
Figure 11. VCR Output Channel for On-Screen Programming.
** CHANNEL ADD/DELETE **
SELECT CHANNEL: [ 02]
SELECT CHANNEL AND
PRESS [ENTER] TO ADD
PRESS [SHIFT] TO DELETE
[SHIFT/ENTER] [MENU]
** CHANNEL SETUP **
ANT/CABLE......... (ANTENNA)
AUTO CHANNEL MEMORY
CHANNEL ADD/DELETE
[SHIFT/ENTER] [MENU]
Press
UP or DN
to select the
desired channel
To Store
and EXIT
** MAIN MENU **
RECORD SPEED ............. (SP)
AUTO REPEAT............... (OFF)
AUDIO OUTPUT..... (STEREO)
CHANNEL SETUP
VCR OUTPUT CH.......... (3CH)
[SHIFT/ENTER] [MENU]
VCR OUTPUT CH.......... (4CH)
To Store
and EXIT
Figure 10. Channel Add/Delete for On-Screen programming.
