VDH910
VIDEOCASSETTE PLAYER/RECORDER
10
** MAIN MENU **
RECORD SPEED ............. (SP)
AUTO REPEAT............... (OFF)
AUDIO OUTPUT ..... (STEREO)
CHANNEL SETUP
VCR OUTPUT CH.......... (3CH)
[SHIFT/ENTER] [MENU]
To View
Main Menu
DESCRIPTION OF ON-SCREEN PROGRAMMING
1. Press MENU on your remote control. The Main Menu
will appear on the screen.
2. Select the item you want to adjust using the SHIFT and the
ENTER buttons on your remote. Press MENU to exit and
store your selection.
If the main menu doesn’t appear, make sure the video source
is tuned to VDH910 output. If the VCR is in the TV tuner
mode, press the TV/VCR button to view the menu.
Using Manual Tracking
Using the Remote Control, you can adjust the picture tracking
manually.
• Automatic tracking is initiated when you first insert a
videocassette in the CASSETTE Compartment.
• Manual tracking may be used when auto tracking does not
fully correct picture tracking noise. Press CH/TRK UP
button to increase or CH/TRK DN button to decrease
manual tracking.
NOTE: If you reach the limit on either TRACKING + or – and
notice no further improvement, the tape may be severely worn or
the unit’s heads may need cleaning.
Press
UP or DN
to select the
desired channel
Figure 5. SHIFT functions on the VDH910’s Remote Control.
Figure 6. Main Menu for On-Screen Programming.
