Model: SRW3881
Maximum Power Handling (Coils in Series) .........600W
Continuous Power (Coils in Series) .....................300W
SPL (Coils in Series) ...........................90.0dB@1W/1m
Frequency Response ................................20Hz-1.5kHz
Cone Material .....Polypropylene w/Titanium Deposition
Woofer Magnet ..........................Strontium Ferrite 50 oz
Woofer Basket .......................................Stamped Steel
Cone Surround Material ............................NBR Rubber
Sealed/Acoustic Suspension
Thiele/Small Parameters
Vented/Bass Reflex
OPTIMUM
Enclosure Airspace (Unfilled) = 2.50 ft
3
Enclosure Airspace (Filled) = 2.10 ft
3
F
3
= 42 Hz
MAXIMUM FLAT
Encl
osure Airspace =
4.0 ft
3
F
b
= 32Hz
F
3
= 31Hz
Por
t
Size = I.D. x
Length: (2) 4" x 14.25"
• Polypropylene Cone
• Rubber Surround
• Dual 4 Ohm Heat Resistant Voice Coil
• Rear Vented Pole Piece
• Large Strontium Ferrite Magnet
• Rubber Magnet Cover
• For Small Sealed or Small Vented Design
Outside Dia 15 3/16" (385.7mm)
Mounting Hole 13 7/8" (352.4mm)
Mounting Depth 6 9/16" (166.0mm)
Sensitivity@1W/1m 87.0/90.0dB
Max. Peak Music 600W
Continuous Power 300W
Nominal Impedance 4/8 Ohms
Re DC Imp (± 10%) 3.30/6.40 Ohms
Le 1.05/4.23mH
V.C. Diameter 2.0" (50.8mm)
V.C. Length 0.945" (24.0mm)
Air Gap 0.314" (8.0mm)
Piston Diameter 13.13" (0.3334m)
Sd 135.3 in
2
(0.0873m
2
)
Vas 3.95ft.
3
(112.0liters)
Fs 35.2Hz
Qts 1.24/0.67
Qes 1.51/0.73
Qms 7.20
Mms 195.8g
Mmd 181.2g
Rms 5.61kg/s
BI 9.7/19.3 Tm
Speaker Displacement 285in.
3
(R)/175in.
3
(F)
Xmax 0.36" (9.2mm)
Magnet Weight 50 oz.
Clarion Corporation of America 661 W. Redondo Beach Blvd., Gardena, CA 90247
Phone: 1-800-GO-CLARION FAX: (310) 327-1999
60
70
80
90
100
110
10 100 1000 Hz
60
70
80
90
100
110
10 100 1000 Hz
21A3987
dB
dB
