Model: SRW2081
Maximum Power Handling (Coils in Series) .........300W
Continuous Power (Coils in Series) .....................150W
SPL (Coils in Series) ...........................85.7dB@1W/1m
Frequency Response ................................20Hz-1.5kHz
Cone Material .....Polypropylene w/Titanium Deposition
Woofer Magnet ..........................Strontium Ferrite 28 oz
Woofer Basket .......................................Stamped Steel
Cone Surround Material ............................NBR Rubber
Sealed/Acoustic Suspension
Thiele/Small Parameters
Vented/Bass Reflex
OPTIMUM
Enclosure Airspace (Unfilled) = 0.48 ft
3
Enclosure Airspace (Filled) = 0.40 ft
3
F
3
= 60 Hz
MAXIMUM FLAT
Encl
osure Airspace =
0.75 ft
3
F
b
= 38Hz
F
3
= 34Hz
Por
t
Size = I.D. x
Length: 2" x
7.0"
• Polypropylene Cone
• Rubber Surround
• Dual 4 Ohm Heat Resistant Voice Coil
• Rear Vented Pole Piece
• Large Strontium Ferrite Magnet
• Rubber Magnet Cover
• For Small Sealed or Small Vented Design
Outside Dia 8 1/4" (208.4mm)
Mounting Hole 7 1/8" (180.3mm)
Mounting Depth 3 13/16" (96.9mm)
Sensitivity@1W/1m 82.7/85.7
Max. Peak Music 300W
Continuous Power 150W
Nominal Impedance 4/8 Ohms
Re DC Imp (± 10%) 3.50/6.80 Ohms
Le 0.80/3.30mH
V.C. Diameter 1.5" (42.2mm)
V.C. Length 0.981" (24.9mm)
Air Gap 0.314" (8.0mm)
Piston Diameter 6.62" (0.1683m)
Sd 34.5 in
2
(0.0222m
2
)
Vas 0.46ft.
3
(13.03liters)
Fs 47.1Hz
Qts 0.98/0.52
Qes 1.12/0.57
Qms 8.20
Mms 60.8g
Mmd 58.9g
Rms 2.18kg/s
BI 7.2/14.4 Tm
Speaker Displacement 85in.
3
(R)/65in.
3
(F)
Xmax 0.38" (9.7mm)
Magnet Weight 28 oz.
Clarion Corporation of America 661 W. Redondo Beach Blvd., Gardena, CA 90247
Phone: 1-800-GO-CLARION FAX: (310) 327-1999
60
70
80
90
100
110
10 100 1000 Hz
60
70
80
90
100
110
10 100 1000 Hz
21A3981
dB
dB
