RDX655Dz 11
When you have entered a title in a CD, it ap-
pears in the sub display. If you have not en-
tered a title, “NO-TITLE” appears in the title
display instead. For information on how to en-
ter a title, refer to the subsection “Entering
titles” in the “Other Handy Functions”.
Setting the Z-enhancer
This unit comes with 3 types of sound tone effects
stored in memory. Select the one you prefer.
The factory default setting is “OFF”.
Each time you press Z-EHCR button 8, the tone
effect changes in the following order:
Z-ENHANCER 1Z-ENHANCER 2Z-
ENHANCER 3OFFZ-ENHANCER 1”...
• Z-ENHANCER 1: bass emphasized
• Z-ENHANCER 2: treble emphasized
Z-ENHANCER 3: bass and treble emphasized
• OFF : no sound effect
Adjusting the tone
Press A-M button $ and select the item to adjust.
Each time you press A-M button $, the item
changes in the following order:
When Z-enhancer 1, 2 or 3 is set
Z-EHCR BAL FAD Function
mode...
Adjusting the bass
1. Press A-M button $ and select “BASS”.
2. Turning the Rotary knob & clockwise empha-
sizes the bass; turning it counterclockwise
attenuates the bass.
The factory default setting is “0”. (Adjustment
range: –6 to +6)
3. When the adjustment is complete, press A-M
button $ several times until the function mode
is reached.
Adjusting the treble
1. Press A-M button $ and select “TREB”.
2. Turning the Rotary knob & clockwise empha-
sizes the treble; turning it counterclockwise
attenuates the treble.
The factory default setting is “0”. (Adjustment
range: –6 to +6)
3. When the adjustment is complete, press A-M
button $ several times until the function mode
is reached.
Basic Operations
Adjusting the balance
1. Press A-M button $ and select “BAL”.
2. Turning the Rotary knob & clockwise empha-
sizes the sound from the right speaker; turn-
ing it counterclockwise emphasizes the sound
from the left speaker.
The factory default setting is “0”. (Adjustment
range: L13 to R13)
3. When the adjustment is complete, press A-M
button $ several times until the function mode
is reached.
Adjusting the fader
1. Press A-M button $ and select “FAD”.
2. Turning the Rotary knob & clockwise empha-
sizes the sound from the front speakers; turn-
ing it counterclockwise emphasizes the sound
from the rear speakers.
The factory default setting is “0”. (Adjustment
range: F12 to R12)
3. When the adjustment is complete, press A-M
button $ several times until the function mode
is reached.
Adjusting the Z-enhancer
1. Press Z-EHCR button 8 and select the Z-
enhancer mode (1 to 3) to adjust.
2. Press A-M button $ and select “Z-EHCR”.
3. Turning the Rotary knob & clockwise adjusts
in the + direction; turning it counterclockwise
adjusts in the – direction.
When Z-enhancer 1 is selected, you can adjust
the bass in the range of ±2.
When Z-enhancer 2 is selected, you can adjust
the treble in the range of ±2.
When Z-enhancer 3 is selected, you can adjust
the bass and treble in the range of ±2.
4. When the adjustment is complete, press A-M
button $ several times until the function mode
is reached.
