1. PRECAUTIONS .............................................................................................................................. 3
2. HANDLING MEMORY CARD ......................................................................................................... 4
3. CONTROLS .................................................................................................................................... 5
MAIN UNIT ...................................................................................................................................... 5
4. NOMENCLATURE ..........................................................................................................................
6
Names of the Buttons and Their Functions ..................................................................................... 6
Display Items ...................................................................................................................................7
LCD Screen .....................................................................................................................................7
5. DCP
(
Detachable Control Panel
)
..................................................................................................8
6. OPERATIONS .................................................................................................................................
9
Basic Operations ............................................................................................................................. 9
Radio Operations .......................................................................................................................... 10
RDS Operations ............................................................................................................................ 12
MP3 Operations ............................................................................................................................ 13
Introduction to
Bluetooth
®
Wireless Technology .............................................................................20
Handsfree Operations ................................................................................................................... 22
Audio Streaming Operations ......................................................................................................... 24
Common Operations ..................................................................................................................... 25
Compatible Devices ...................................................................................................................... 30
7. ADDITIONAL INFORMATION ......................................................................................................
31
8. TROUBLESHOOTING
..................................................................................................................33
9. ERROR DISPLAYS
...................................................................................................................... 36
10. SPECIFICATIONS
........................................................................................................................ 37
4
FB278RBT
Contents
CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BY THE MANUFAC-
TURER WILL VOID THE WARRANTY.
INFORMATION FOR USERS:
Be sure to unfold and read the next page. / Veuillez déplier et vous référer à la page suivante.
Bitte ausbreiten und die nächste Seite lesen. / Assicurarsi di aprire e leggere la pagina successiva.
Volgende pagina uitvouwen en doorlezen a.u.b. / Cerciórese de desplegar y de leer la página siguiente.
Glöm inte att vika ut och läsa nästa sida. / Não deixe de abrir e ler a próxima página.
English
3
FB278RBT
FB278RBT
8
English
5. DCP
(
Detachable Control Panel
)
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a resi
-
dential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio communica-
tions. However, there is no guarantee that interfer-
ence will not occur in a particular installation.
1. PRECAUTIONS
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to consult the dealer or an
experienced radio/TV technician for help.
Do not leave the card in vehicle where there
is high temperature or direct sunlight or
where electromagnetic waves or electrostatic
are easily generated.
SD/MMC Memory Card
When the card is being read, do not remove
the card.
After eject operation, always remove the
memory card from the slot; otherwise, the flip
down panel may not be closed properly.
After usage, store the supplied memory card
in the enclosed case.
Do not bend or drop the card. The card or
the recorded content may be damaged.
Do not touch the terminals on the back of the
card with your fingers.
Do not allow dirt, dust or water to enter it.
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the DCP
(
Detachable Control Panel
)
case to
prevent scratches.
We recommend taking the DCP with you when
leaving the car.
2. Press in the
[
RELEASE
]
button.
3. Pull the DCP toward you and remove it.
Removing the DCP
1. Press the
[
SRC
]
button for 1.5 seconds or
longer to switch off the power.
∗ The flip down panel can only be opened up
to 65˚, please do not forcibly push to open
further.
The DCP can easily be damaged by shock.
After removing it, be careful not to drop it
or subject it to strong shocks.
The connector connecting the main unit and
the DCP is an extremely important part. Be
careful not to damage it by pressing on it
with fingernails, pens, screwdrivers, etc.
CAUTION
!
Note:
If the DCP is dirty, wipe off the dirt with a soft, dry
cloth only.
4. Close the HOLD FLAP.
Attaching the DCP
1. Insert the right side of the DCP into the main
unit.
2. Insert the left side of the DCP to attach into the
main unit.
2. HANDLING MEMORY CARD
Storing the DCP in the DCP case
Hold the DCP, in the orientation as shown in the
figure below, and put it into the supplied DCP case.
(
Ensure the DCP is in the correct orientation.
)
SD Logo is a trademark.
The
Bluetooth
®
word mark and logos are owned by the
Bluetooth
®
SIG, Inc. and any use of such marks by Clarion Co.,Ltd. is
under license. Other trademarks and trade names are those of their respective owners.
