DXZ735MP 23
English
Operations Common to Each Mode
AUX function
This system has an external input jack so you
can listen to sounds and music from external
devices connected to this unit.
Dual zone
Dual zone function is operating 2 sound sorces
at same time for multi users. This unit can con-
trol and output the internal sound source (for ex-
ample, Tuner CD/MP3/WMA Aux) and sound
sorce from external unit connected with Ce-NET
(for example Sirius digital tuner CD/MD/DVD
changer TV(VTR) Aux) at same time.
Each of 2 sound sorces output to 2 listening
zones. they are called main zone and sub zone.
Main zone source is output from vehcle speak-
ers and sub zone source is output from wireless
head phone system WH100/200 (sold
seperately).
Notes:
• Simultaneous use of internal sound souces or
use of external sound sources are not available
except Aux.
• TV tuner mode automaticaly select VTR input.
• ISR function is not operating while Dual zone ON.
• Audio mode and Z-enhancer function only avail-
able in main zone.
• Color setting are possible to both main and sub
zone indpependently.
Dual zone operation
Factory default setting is Dual zone OFF, Dual
zone operation mode is main zone, sub zone
function is Aux.
Turning on/off the dual zone mode
1.
Press and hold the [DZ] button for 1 second
or longer to turn on or off the dual zone mode.
“DUAL ZONE” indicator appears in the dis-
play.
Select the function
1. Press the [DZ] button to switch the control
zone between main zone or sub zone.
2. Press the [FNC] button to select the function
in the control zone.
Volume control
Only a main zone is possible for volume control.
volume control of sub zone is only by wireless
head phone system WH100/200.
1. Turn the [ROTALY] knob clockwise or coun-
terclockwise to main zone volume increase
or decrease.
Reverse function
This unit can switch the Sound sorce between
main or sub zone.
Press and hold The [I] button to switch the main
and sub zone sound source. “REVERSE” ap-
pears on the display for 2 seconds.
