●When the TV is connected
∗
For details, see the section “TV operations”.
[Scan] button
• Perform preset scan while in the TV mode.
When the button is pressed and held, auto
store is performed.
[Repeat] button
• Switches between ST and MONO.
When pressed and held for 1 second:
Switches between MAIN and SUB.
[Random] button
• Switch the TV picture mode or VTR (external)
picture mode.
[Band] button
• Switch the band.
• When the button is pressed and held, switch
seek tuning or manual mode.
[Preset] knob
• Preset a station to start with in the TV mode.
[A], [D] buttons
• Select a station.
4. NOMENCLATURE
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold).
[CD Slot]
• CD insertion slot.
[MD Slot]
• MD insertion slot.
[CD Eject] button
• Eject a CD when it is loaded into the unit.
[MD Eject] button
• Eject a MD when it is loaded into the unit.
[Rotary] knob
• Adjust the volume by turning the knob clock-
wise or counterclockwise.
• Use the knob to perform various settings.
[s] button
• Play or pause while in the CD/MD mode.
[Audio Mode] button
• Use the button to switch to the audio mode
(bass/treble, balance/fader Z-Enhancer Plus)
• Press and hold for 1 second or longer to turn
on or off the MAGNA BASS EX.
[Scan] button
• Perform scan play for 10 seconds of each
track while in the CD/MD mode.
• Press and hold the button for 1 second or
longer to perform folder (group) scan play in
the MP3/MD disc.
• Perform preset scan while in the radio mode.
When the button is pressed and held, auto
store is performed.
[Repeat] button
•
Perform repeat play while in the CD/MD mode.
• Press and hold the button for 1 second or
longer to perform folder (group) repeat play in
the MP3/MD disc.
[Random] button
•
Perform random play while in the CD/MD mode.
• Press and hold the button for 1 second or
longer to perform folder (group) random play
in the MP3/MD disc.
[Color] button
• Button’s color change to multicolor.
• Press and hold to enter the color adjustment
mode while the User Color is on.
[Title] button
•
Use the button to input a title in the Tuner, CD mode.
• Press and hold the button for 1 second or
longer to enter the adjust mode.
Names of the Buttons and their Functions
[Display] button
• Switch the display indication (Main display,
Title display, Clock display).
• When the button is pressed and held,
switches the disc titles, group titles or track
titles while in the MD mode.
• When the button is pressed and held,
switches the user titles or track titles, etc.
while in the CD mode.
[I.S.R] button
• Recall ISR radio station in memory.
•
Press and hold for 2 seconds or longer: Store cur-
rent station into ISR memory (radio mode only).
[Band] button
• Switch the band, or seek tuning or manual
tuning while in the radio mode.
•Play a first track while in the CD/MD mode.
• Press and hold for 1 second or longer to turn
on or off the group mode. when playing a
group-edited MD
[Memory] button
•
Press and hold for 1 second or longer to turn on
or off the play list mode. (MP3/WMA disc only)
• Register a preset memory.
[Function] button
• Press the button to turn on the power.
Press and hold the button for 1 second or
longer to turn off the power.
• Switches the operation mode among the ra-
dio mode, etc.
[Preset] knob
• Preset a station to start with in the radio
mode.
• Select the folder (group) in the MP3/MD disc.
• Select an item for various settings (in the ad-
just mode).
[A], [D] buttons
•
Select a station while in the radio mode or se-
lect a track when listening to a CD/MD. These
buttons are used to make various settings.
• Press and hold the button for 1 second or
longer to switch the fast-forward/fast-back-
ward.
[Z-Enhancer+] button
•
Use the button to select one of the 3 types of
sound characteristics already stored in memory.
[D.S.P] button
• Select the DSP mode.
Major button operations when external equipment is
connected to this unit
3.CONTROLS /
Source unit /
[
D.S.P
]
[
Memory
]
[
Band
]
[
I.S.R
]
[
Display
][
Color
][
Title
]
[
Random
]
[
Repeat
]
[
Scan
]
[
Audio Mode
]
[A], [D]
[
CD Slot
]
[
Function
]
[
Preset
]
[
Rotary
]
[
s
]
[
Z-Enhancer
+
]
[
MD Slot
]
[
CD Eject
]
[
MD Eject
]
Receiver for remote control unit
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
리모컨 수광부
●When the CD/MD/DVD changer
is connected
∗ For details, see the section “CD/MD
changer operations”. For the DVD
changer, refer to the Owner’s Manual pro-
vided with the DVD changer.
[s] button
• Play or pause a CD, MD or DVD.
[Scan] button
• Perform scan play for 10 seconds of each
track. Disc scan play is performed when the
button is pressed and held.
[Repeat] button
•
Perform repeat play. Disc repeat
play is per-
formed when the button is pressed and held.
[Random] button
•
Perform random play. Disc random
play is per-
formed when the button is pressed and held.
[Title] button
• Use the button to input a title in the CD
changer mode.
•
Use the button to scroll the title during CD-text
play or MD changer play in the MD changer mode.
[Display] button
• When the button is pressed and held,
switches the disc titles or track titles while in
the MD changer mode.
• When the button is pressed and held,
switches the user titles or track titles, etc.
while in the CD changer mode.
[Band] button
• Move the next disc in increasing order.
[Preset] knob
• Select the disc.
[A], [D] buttons
• Select a track when listening to a disc.
•
Press and hold the button for 1 second or
longer to switch the fast-forward/fast-backward.
Operation status indication : Main, titles, clock, etc. are displays.
작동 상태 : 메인 화면, 제목, 시계 등이 표시
Function mode indication : The names of modes being selected,
etc. are displayed.
기능 모드 : 선택된 모드 등이 표시
Preset channel indication (1 to 6) /프리셋 채널 (1 - 6)
Disc number indication (1 to 12) /디스크 번호 (1 - 12)
:
MAGNA BASS EX indication
MAGNA BASS EX
: DSP indication/DSP
: Z-Enhancer Plus indication
Z-Enhancer Plus
: LP2 indication /LP2
: LP4 indication /LP4
: MP3 indication /MP3
: WMA indication /WMA
: Group disc indication
그룹 디스크
: Stereo indication
스테레오
: Mute indication
음소거
: Manual indication
수동 모드
: Group (Random, Repeat, Scan) indication
그룹(랜덤, 반복, 스캔)
: Disc (Random, Repeat, Scan) indication
디스크(랜덤, 반복, 스캔) 표시
:
Folder (Random, Repeat, Scan) indication
폴더 (랜덤, 반복, 스캔) 표시
: Random indication /랜덤
: Repeat indication /반복
: Scan indication /스캔
: Group indication /그룹
Display Items/
==
==
=
==
==
=
LCD Screen/
i`a=i`a=
i`a=i`a=
i`a=
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
