Clarion DB325am/ CD Player User Manual



DB325 17
English
FM Tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 11 dBf
50 dB Quieting Sensitivity: 17 dBf
Alternate Channel Selectivity: 75 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
AM Tuner
Frequency Range: 530 kHz to 1,710 kHz
Usable Sensitivity: 25
µ
V
CD Player
System: Compact disc audio system
Usable Discs: Compact disc
Frequency Response: 10 Hz to 20 kHz (±1 dB)
Signal-to-Noise Ratio: 100 dB (1 kHz) IHF-A
Dynamic Range: 95 dB (1 kHz)
Harmonic Distortion: 0.01%
Audio
Maximum Power Output:
200 W (50 W × 4 ch)
Continuous Average Power Output:
18 W × 4, into 4 , 20 Hz to 20 kHz,1%THD
Bass Control Action (30 Hz): ±12 dB
Treble Control Action (10 kHz): ±10 dB
Line Output (CD 1 kHz, 10 k): 1.8 V
General
Power Supply Voltage: 14.4 V DC (10.8 V to 15.6
V allowable), negative ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 (4 to 8 allowable)
Weight: 3.97 lb. (1.8 kg)
Dimensions:
7
(178 mm) Width × 2
(50 mm) Height ×
6-1/8
(155 mm) Depth
Notes:
Specifications and design are subject to change with-
out notice for further improvement.
2
2-1/4
7
7-3/8
6-1/8
(50 mm)(178 mm)
(58 mm)(188 mm)
(155 mm)
11. SPECIFICATIONS
