Clarion DB166 CD Player User Manual



10 DB166
280-8351-00
English
Loading a CD
Insert a CD into the center of the CD SLOT with
the labeled side facing up. LOADING appears
in the display, the CD enters into the slot, and
the play starts.
For CD (12 cm) For single CD (8 cm)
CD SLOT
Notes:
Never insert foreign objects into the CD SLOT.
If the CD is not inserted easily, there may be
another CD in the mechanism or the unit may
require service.
Discs not bearing the mark and CD-ROMs
cannot be played by this unit.
Some CDs recorded in CD-R/CD-RW mode may
not be usable.
Loading 8 cm compact discs
No adapter is required to play an 8 cm CD.
Insert the 8 cm CD into the center of the insertion
slot.
Listening to a CD already inserted
Press the [SRC] button to select the CD mode.
Play starts automatically. If no CD is loaded in
the unit, NO DISC appears in the display.
Pausing play
1. Press the [ ] button to pause play.
PAUSE appears in the display.
2. To resume CD play, press the [ ] button again.
Ejecting a CD
1. Press the [Q] to eject the CD. Take it out
from the ejected position.
Note:
If you force a CD into before auto reloading, this
can damage the CD.
If a CD (12 cm) is left in the ejected position for 15
seconds, the CD is automatically reloaded (Auto reload).
8 cm CDs are not auto reloaded. Be sure to remove
it when ejected.
Selecting a track
Track-up
1. Press the [] button to move ahead to the
beginning of the next track.
2.
Each time you press the [] button, the track
advances ahead to the beginning of the next track.
CD Operations
Manual memory
1. Select the desired station with seek tuning,
manual tuning or preset tuning.
2. Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store the current
station into preset memory.
Auto store
Auto store is a function for storing up to 6
stations that are automatically tuned in
sequentially. If 6 receivable stations cannot be
received, a previously stored station remains
unoverwritten at the memory position.
1. Press the [BND] button and select the
desired band.
2. Press and hold the [ ] button for 2
seconds or longer. The stations with good
reception are stored automatically to the
preset channels.
Preset scan
Preset scan receives the stations stored in
preset memory in order. This function is useful
when searching for a desired station in memory.
1. Press the [ ] button.
2. When a desired station is tuned in, press the
[ ] button again to continue receiving that
station.
Note:
Be careful not to press and hold the [ ] button
for 2 seconds or longer, otherwise the auto store
function is engaged and the unit starts storing
stations.
Instant station recall (ISR)
Instant station recall is a special radio preset
that instantly accesses a favorite radio station at
a touch of a button. The ISR function even
operates with the unit in other modes.
ISR memory
1. Select the station that you wish to store in ISR
memory.
2. Press and hold the [ISR] button for 2 seconds
or longer.
Recalling a station with ISR
In any mode, press the [ISR] button to turn on the
radio function and tune the selected radio station.
ISR appears in the display. Press the [ISR]
button again to return to the previous mode.
Radio Operations
