MOUNTING METHOD
METHODE DE MONTAGE
Main unit
Unite principal
Speaker
Haut-parleur
Part No. CM16-011205
Fiberglass panel
Panneau de fibre de verre
Speaker
Haut-parleur
Grille
Gril
Mounting screw (4)
Vis de Montage (4)
"ATTENTION"
Speaker edge is very sharp.
Le bord de l'enciente
est tres tranchant.
Speed nut (4)
Ecrou de vitesse (4)
L
R
WIRING DIAGRAM
DIAGRAMME DE CABLAGE
