• Z-ENHANCER 3: bass and treble emphasized
• Z-EHCR OFF: no sound effect
Loudness Effect
In order to turn on/off the loudness effect, use
the LD button 2 for 1 second or longer. Every
time the LD button 2 is pressed and held for 1
second or longer, the loudness effect switches
on and off.
*
When the loudness effect is on, the display will show
“LD”.
Switching the Display
Every time the DISP button 5 is pressed, the
display will change between the main display
and the clock display.
Setting the Clock
1) Press the DISP button 5 to display the clock
display.
2) Press and hold the DISP button 5 for 1 sec-
ond or longer.
3) Press the SRCH Left button @, then set the
current hour.
4) Press the SRCH Right button @, then set the
current minute.
5) Press the DISP button 5, then the clock is
set.
Notes:
•
If you select another operation mode while you are
setting the clock, the clock setting operation will be
canceled.
•
If you remove the vehicle’s battery for a check or
repair, the clock will be reset, so you must set it again.
Radio Mode Operations
FM Reception
For enhanced FM performance the
®
tuner includes signal actuated stereo control and
Multipath noise reduction circuits.
Listening to the Radio
1) Press the FNC button 3 to select the radio
mode, then the radio will be on.
2) To select a preset band, press the BND but-
ton !, then select one of the preset bands
such as FM1, FM2, FM3, or AM. Every time
the BND button ! is pressed, the display will
change as:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1
3) Press the SRCH Left/Right button @, then
the station at which there is a broadcast will
be selected (Seek selection).
Mute
Use this function to turn off the sound immedi-
ately.
Press the MUTE button $. The sound turns off
and “MUTE” appears on the display. Press the
MUTE button again to cancel the mute mode.
Manual Tuning
1) Press the BND button !, then select FM1,
FM2, FM3 or AM.
2) Press and hold the BND button ! for 1 sec-
ond or longer, then the display will show
“MANU”, which means that a manual selec-
tion function is on.
3) Press the SRCH Left/Right button @ and
select the right station.
Seek Tuning
1) Press the BND button !, then select FM1,
FM2, FM3 or AM.
2) If the “MANU” on the display is on, press and
hold the BND button ! for 1 second or
longer. When the “MANU” display is off, the
Seek Selection function is on.
3) Press the SRCH Left/Right button @, then
when it selects the station in which there is a
broadcast, it automatically stops.
BD416 11
E glis
Main display
Clock display
Main display ...
